The Sensor Distance, as described in Table 5-6,
using the slots cut in the 6-foot Logic template.
The Sensor Distance, as described in Table 5-6,
using a scale.
4.00-inch mark
3.25-inch mark
Product Service 1-800-522-7658
Figure 5-19
Figure 5-20
