6. Using a 1/2 -inch socket or wrench, loosen the four exhaust filter sealing bolts
located at each corner of the exhaust filter tray, as shown in Figure 6-17, at least
1/2 inch. This releases the exhaust HEPA filter from the cabinet.
Exhaust HEPA Filter bolts
(2 per each side)
7. Pull the exhaust HEPA filter straight out of the cabinet.
To Remove the Exhaust HEPA Filter on 3-foot models:
1. Follow steps 1-5 as above.
2. Loosen the four sealed exhaust filter bolts on the top of the cabinet hull, as
shown in Figure 6-18 and 6-19.
3. Remove the exhaust filter by pulling it straight out of the cabinet.
Exhaust HEPA Filter bolts
Product Service 1-800-522-7658
Figure 6-17
Figure 6-18
