Inflow Test Specifications – 8 inch Sash Opening
Nominal Average Inflow
Sash Open Area (Sq. Ft)
Nominal Avg. Exhaust Vol.
Avg. Exhaust Vol. Range
Inflow Test Specifications – 9 inch Sash Opening
Nominal Average Inflow
Sash Open Area (Sq. Ft)
Nominal Avg. Exhaust Vol.
Avg. Exhaust Vol. Range
Inflow Test Specifications – 10 inch Sash Opening
Nominal Average Inflow
Sash Open Area (Sq. Ft)
Nominal Avg. Exhaust Vol.
Avg. Exhaust Vol. Range
Inflow Test Specifications – 12 inch Sash Opening
Nominal Average Inflow
Sash Open Area (Sq. Ft)
Nominal Avg. Exhaust Vol.
Avg. Exhaust Vol. Range
Acceptance
Average inflow shall be meet the specified value.
Width (feet) 3
105+/-5
(FPM)
2.03
213
(CFM)
203-223
(CFM)
Width (feet) 3
105+/-5
(FPM)
2.28
240
(CFM)
228-251
(CFM)
Width (feet) 3
105+/-5
(FPM)
2.53
266
(CFM)
253-278
(CFM)
Width (feet) 3
85+/-5
(FPM)
3.04
259
(CFM)
243-274
(CFM)
Product Service 1-800-522-7658
4 5 6
105+/-5 105+/-5 105+/-5
2.69 3.36 4.03
283 353 423
269-296 336-370 403-443
4 5 6
105+/-5 105+/-5 105+/-5
3.03 3.78 4.53
318 397 476
303-333 378-416 453-498
4 5 6
105+/-5 105+/-5 105+/-5
3.37 4.2 5.03
354 441 529
337-371 420-462 503-553
4 5 6
85+/-5 85+/-5 85+/-5
4.04 5.04 6.04
344 428 514
323-364 403-454 483-544
Table 5-5
