Wall-Mounted Touch Screen Monitor (Standard)
Steps
If you do not order the ceiling arm, the wall mount is delivered by default.
Mount the wall mount for monitor to solid walls.
66
Attach the 100 mm VESA adapter plate to
2.
the arm.
Close the cable channel with the supplied
3.
covers (cut to fit).
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x
