APPENDIX
Recess Dimensions for 17'' Floor Box
The following image shows recommended dimension for recess to fit in the floor box:
TOP VIEW
Cutting of the floor box recesses severely influences building statics. A stress analyst
approval/clearance is mandatory.
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x
483mm
45°
813mm
SIDE VIEW
finished floor
Figure 50
117
