PREINSTALLATION CHECKLISTS
13.3

Electrical Infrastructure

Checklist
Yes No n/a
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x
3 Electrical Infrastructure
3.1 Provide a power distribution box.
Provide the schemas of the power
3.2
distribution box.
Provide flexible power cable with
400 VAC, three phase + neutral N
+ ground PE, 50/60 Hz; maximum
3.3 wire cross section of 35 mm²
(4AWG) to the bottom of the gen-
erator with a minimum of 2 m
slack. TN star network is required.
Provide flexible power cable with
230 VAC, one phase + neutral N +
ground PE, 50/60 Hz; maximum
3.4
wire cross section: 2.5 mm² to the
bottom of the computer cabinet
with a minimum of 2 m slack.
For safety reasons:
It is required to install a power
switch close to the computer cabi-
3.5
net and X-ray generator.
Alternative: Locker system in your
electric distribution panel.
Connection of the power lines to
the computer cabinet and X-ray
3.6 generator must be performed by
your electrician supported by a
Brainlab technician.
PEQ reference bar: To be instal-
led by customer near generator or
3.7
computer cabinet, connect all
Brainlab grounding cables.
PEQ 16 mm² cable between PEQ
3.8 reference bar and computer cabi-
net.
PEQ 16 mm² cable between PEQ
3.9 reference bar and X-ray genera-
tor.
Install a network plug RJ 45 close
3.10 to the computer cabinet (maxi-
mum 2 m from the cabinet).
Comments
Your power distribution box
must provide the power and
if applicable the required sig-
nals to the ExacTrac equip-
ment. An on/off circuit should
allow you to safely power on
or down the equipment.
By providing the schemas of
the power distribution box to
be built, Brainlab can guaran-
tee if the requirements for
ExacTrac are met.
The power cut off must be
protected by a unique key.
Standard keys are not ac-
cepted by Brainlab.
Scheduled
