Ceiling Brackets

13.2 Ceiling Brackets
Checklist
Yes No n/a
122
2 Ceiling Brackets
Mark position anchors on the ceil-
2.1
ing.
Remove obstacles/providing alter-
2.2
native anchoring platforms.
2.3 Provide anchors.
Assemble and fix ceiling brackets:
2.4
IR camera mount; 200 kg
Assemble and fix ceiling brackets:
2.5
Flat panel mounts (x 2); 200 kg.
Fix steel rope angle plates (x 4); L
2.6
configuration.
2.7 Assemble and fix ceiling brackets.
Assemble and fix the wall monitor
2.8 mount; 10 kg and ceiling mounted
monitor arm; 400 kg.
Fix the in-room distribution box; 6
2.9
kg
Fix the control-room distribution
2.10
box; 6 kg.
Fix the Brainlab warning lights; 1
2.11
kg.
You must provide a written "State-
ment of Compliance" about fixa-
tion of all ceiling mounts and floor
2.12
boxes in accordance to respective
local regulations and Brainlab pre-
installation parameters.
Adapt the false ceiling to the new
2.13 penetrations (from ceiling brack-
ets).
Storage of Brainlab's cables until
2.14
final installation.
Comments
The contractor must provide
the appropriate anchors to
hold the weight of the ceiling
brackets.
The contractor statement of
compliance is mandatory to
complete the acceptance
protocols.
The final position of the
Brainlab suspending equip-
ment cannot be precise until
the end of the installation.
The false ceiling must be
adapted after Brainlab has
completed installation.
Brainlab's data cables are
delivered together with the
ceiling brackets. They must
be kept in a safe place until
their installation or until they
are pulled.
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x
