PREINSTALLATION CHECKLISTS

13 PREINSTALLATION
CHECKLISTS
13.1

Floor Boxes

Checklist
Yes No n/a
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x
1 Floor Boxes
1.1 Marking recess on the floor.
1.2 Digging the recess.
Bottom surface of recess must be
1.3
leveled no deeper than 33 cm.
1.4 Align and level the floor boxes.
Fix the floor boxes to the ground.
1.5 Brainlab does not provide the an-
chors.
Install conduits (minimum 100 mm
inner diameter, preferably rigid
1.6 PVC tubes) from the floor boxes
to the cable through the bunker
rear wall --> to the generator.
1.7 Concrete pouring.
1.8 Finished floor.
Storage of floor box aluminium
covers and all included items
1.9
within the floor box until final in-
stallation.
Comments
The final covers and all in-
cluded items within the floor
box are placed during system
installation.
They must be kept in a safe
place until installed by the
Brainlab team.
Scheduled
121
