Brainlab ExacTrac Planning Manual page 60

Ceiling-Mounted Touch Screen Monitor (Optional)
Dimensions of the Upper Ceiling Plate (Red)
Dimensions of the Lower Ceiling Plate (Black)
60
holes (6x) for threaded
rods to interface plate
holes (4x) for fixation
of plate to the ceiling
t=15mm
t=15mm
M16(6x)
523mm
Figure 28
holes (6x) for threaded
rods to ceiling plate
M16(6x)
0.5
Figure 29
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x
6x60°
90°
holes (6x) for threaded
rods Brainlab
(installation of lower part)
