6.1.6 VLT ®
EtherNet/IP MCA 121
Ethernet is the future standard for communication at the
®
factory floor. The VLT EtherNet/IP MCA 121 option is
based on the newest technology available for industrial
use and handles even the most demanding requirements.
EtherNet/IP™ extends standard commercial Ethernet to the
Common Industrial Protocol (CIP™) – the same upper-layer
protocol and object model found in DeviceNet.
MCA 121 offers advanced features such as:
•
Built-in, high-performance switch enabling line-
topology, which eliminates the need for external
switches.
•
DLR Ring (from October 2015).
•
Advanced switch and diagnosis functions.
•
Built-in web server.
•
E-mail client for service notification.
•
Unicast and Multicast communication.
6.1.7 VLT ®
Modbus TCP MCA 122
The MCA 122 option connects to Modbus TCP-based
networks. It handles connection intervals down to 5 ms in
both directions, positioning it among the fastest
performing Modbus TCP devices in the market. For master
redundancy, it features hot swapping between 2 masters.
Other features include:
•
Built-in web-server for remote diagnosis and
reading out basic drive parameters.
•
Email notification that can be configured to send
an email message to 1 or more recipients when
certain alarms or warnings occur, or when they
are cleared.
•
Dual master PLC connection for redundancy.
6.1.8 VLT ®
BACnet/IP MCA 125
®
The VLT BACnet/IP MCA 125 option allows quick and easy
integration of the drive into building management systems
(BMS) using the BACnet/IP protocol or by running BACnet
on Ethernet. It can read and share data points and transfer
actual and requested values to and from the systems.
The MCA 125 option has 2 Ethernet connectors, enabling
daisy-chain configuration with no need for external
switches. The embedded 3-port managed switch of the
®
VLT BACnet/IP MCA 125 option comprises 2 external and
1 internal Ethernet port. This switch allows the use of a
line structure for the Ethernet cabling. This option makes it
possible to control multiple high-efficiency permanent
MG16C302
Design Guide
magnet motors in parallel and monitor points required in
typical HVAC applications. Besides standard functionality,
the MCA 125 option features:
•
•
•
•
•
•
•

6.2 Functional Extensions

This section describes the functional extension options that
are available with the VLT
numbers, refer to chapter 13.2 Ordering Numbers for
Options/Kits.
6.2.1 VLT
MCB 101
The MCB 101 option offers an extended number of control
inputs and outputs:
•
•
•
•
•
6.2.2 VLT
The MCB 105 option extends relay functions with 3 more
relay outputs.
•
•
Maximum switch rate (rated load/minimum load)
6 minutes
Maximum terminal load
AC-1 resistive load: 240 V AC, 2 A.
6.2.3 VLT
®
The VLT
drive for upgrading to advanced performance and control
using the additional inputs/outputs. This option also
upgrades the drive with a battery back-up supply for the
Danfoss A/S © 11/2017 All rights reserved.
COV (change of value).
Read/write property multiple.
Alarm/warning notifications
Ability to change BACnet object names for user-
friendliness.
BACnet Loop object.
Segmented data transfer.
Trending, based on time or event.
®
HVAC Drive series. For ordering
®
General Purpose I/O Module
3 digital inputs 0–24 V: Logic 0 < 5 V; Logic 1 >
10 V.
2 analog inputs 0–10 V: Resolution 10 bits plus
sign.
2 digital outputs NPN/PNP push-pull.
1 analog output 0/4–20 mA.
Spring-loaded connection.
®
Relay Card MCB 105
Protects control cable connection.
Spring-loaded control wire connection.
-1 /20 s -1 .
®
Analog I/O Option MCB 109
Analog I/O Option MCB 109 is easily fitted in the
