6 Options and Accessories Overview

6.1 Fieldbus Devices

This section describes the fieldbus devices that are
®
available with the VLT AQUA Drive series. Using a fieldbus
device reduces system cost, delivers faster and more
efficient communication, and provides an easier user
interface. For ordering numbers, refer to
chapter 13.2 Ordering Numbers for Options and Accessories.
6.1.1 VLT ®
PROFIBUS DP V1 MCA 101
The MCA 101 provides:
•
Wide compatibility, a high level of availability,
support for all major PLC vendors, and compati-
bility with future versions.
•
Fast, efficient communication, transparent instal-
lation, advanced diagnosis, and parameterization
and auto-configuration of process data via GSD
file.
•
Acyclic parameterization using PROFIBUS DP-V1,
PROFdrive, or Danfoss FC profile state machines.
6.1.2 VLT ®
DeviceNet MCA 104
The MCA 104 provides:
•
Support of the ODVA AC drive profile supported
via I/O instance 20/70 and 21/71 secures compati-
bility to existing systems.
•
Benefits from ODVA's strong conformance testing
policies that ensure products are interoperable.
6.1.3 VLT ®
PROFINET MCA 120
The MCA 120 option combines the highest performance
with the highest degree of openness. The option is
designed so that many of the features from the VLT
PROFIBUS MCA 101 can be reused, minimizing user effort
to migrate PROFINET and securing the investment in a PLC
program.
•
Same PPO types as the VLT
MCA 101 for easy migration to PROFINET.
•
Built-in web server for remote diagnosis and
reading out of basic drive parameters.
•
Supports MRP.
•
Supports DP-V1. Diagnostic allows easy, fast, and
standardized handling of warning and fault
MG22B102
Design Guide
6.1.4 VLT
Ethernet is the future standard for communication at the
factory floor. The VLT
based on the newest technology available for industrial
use and handles even the most demanding requirements.
EtherNet/IP™ extends standard commercial Ethernet to the
Common Industrial Protocol (CIP™) – the same upper-layer
protocol and object model found in DeviceNet.
MCA 121 offers advanced features such as:
6.1.5 VLT
The MCA 122 option connects to Modbus TCP-based
networks. It handles connection intervals down to 5 ms in
both directions, positioning it among the fastest
performing Modbus TCP devices in the market. For master
redundancy, it features hot swapping between 2 masters.
Other features include:
®
®
PROFIBUS DP V1

6.2 Functional Extensions

This section describes the functional extension options that
are available with the VLT
numbers, refer to chapter 13.2 Ordering Numbers for Options
and Accessories.
Danfoss A/S © 05/2017 All rights reserved.
information into the PLC, improving bandwidth in
the system.
•
Supports PROFIsafe when combined with VLT
Safety Option MCB 152.
•
Implementation in accordance with Conformance
Class B.
®
EtherNet/IP MCA 121
®
EtherNet/IP MCA 121 option is
•
Built-in, high-performance switch enabling line-
topology, which eliminates the need for external
switches.
•
DLR Ring (from October 2015).
•
Advanced switch and diagnosis functions.
•
Built-in web server.
•
E-mail client for service notification.
•
Unicast and Multicast communication.
®
Modbus TCP MCA 122
•
Built-in web-server for remote diagnosis and
reading out basic drive parameters.
•
Email notification that can be configured to send
an email message to 1 or more recipients when
certain alarms or warnings occur, or when they
are cleared.
•
Dual master PLC connection for redundancy.
®
AQUA Drive series. For ordering
®
