8.10 F11 Exterior and Terminal Dimensions
8.10.1 F11 Exterior Dimensions
2280
(89.7)
8
8
Illustration 8.72 Front, Side, and Door Clearance Dimensions for F11
136
VLT
2400 (94.5)
776
776
(30.6)
(30.6)
Danfoss A/S © 11/2017 All rights reserved.
®
HVAC Drive FC 102
776
(30.6)
2204
(86.8)
606
(23.9)
MG16C302
