8.5 F3 Exterior and Terminal Dimensions
8.5.1 F3 Exterior Dimensions
2280
(89.7)
578
(22.8)
Illustration 8.33 Front, Side, and Door Clearance Dimensions for F3
MG16C302
Design Guide
2000 (78.8)
776
578
(30.6)
(22.8)
Danfoss A/S © 11/2017 All rights reserved.
606
(23.9)
2204
(86.8)
8
8
97
