Model Enclosure size
P355 F8–F9
P400 F8–F9
P500 F8–F9
P560 F8–F9
P630 F10–F11
P710 F10–F11
P800 F10–F11
P900 F12–F13
P1M0 F12–F13
P1M2 F12–F13
Table 10.25 Mains Fuses, 525–690 V
Model Bussmann PN
P450
P500
P560
P630
P710
P800
Table 10.26 Inverter Module DC Link Fuses, 380–480 V
Model Bussmann PN
P630
P710
P800
P900
P1M0
P1M2
Table 10.27 Inverter Module DC Link Fuses, 525–690 V
The 170M fuses from Bussmann shown use the -/80 visual indicator. -TN/80 Type T, -/110, or TN/110 Type T indicator fuses
of the same size and amperage can be substituted for external use. To meet UL requirements, use any minimum 480 V UL
listed fuse with associated current rating.
Enclosure Models
F3 380–480 V, Model: P450
525–690 V, Model: P630–P710
F3 380–480 V, Model: P500–P630
525–690 V, Model: P800
F4 380–480 V, Model: P710
525–690 V, Model: P900–P1M2
F4 380–480 V, Model: P800
Table 10.28 Circuit Breakers, F3–F4
MG16C302
Design Guide
Rating
[V] (UL) [A]
700 630
700 630
700 630
700 630
700 900
700 900
700 900
700 1500
700 1500
700 1500
Rating
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M6467 1400 A, 700 V
170M6467 1400 A, 700 V
170M8611 1100 A, 1000 V
170M6467 1400 A, 700 V
Rating
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
Type
Merlin Gerin
NPJF36120U31AABSCYP
Merlin Gerin
NRJF36200U31AABSCYP
Merlin Gerin
NRJF36200U31AABSCYP
Merlin Gerin
NRJF36250U31AABSCYP
