Danfoss VLT HVAC Drive FC 102 Design Manual page 181

Electrical Installation Con...
Model Recommended drive
external fuse
Bussmann PN
P630
P710
P800
P900
P1000
P1200
Table 10.16 525–690 V, Enclosure F, Mains Fuse Options for UL Compliance
Model
P630
P710
P800
P900
P1000
P1200
Table 10.17 525–690 V, Enclosure F, Inverter Module DC Link Fuses
The 170M fuses from Bussmann shown use the -/80 visual indicator. -TN/80 Type T, -/110, or TN/110 Type T indicator fuses
of the same size and amperage can be substituted for external use. To meet UL requirements, use any minimum 500 V UL
listed fuse with associated current rating.
10.5.2 Supplementary Fuses
Enclosure
E and F
Table 10.18 SMPS Fuse
Size/type
P355–P400, 525–690 V
P315-P800, 380–480 V
P500–P1M2, 525–690 V
Table 10.19 Fan Fuses
MG16C302
Design Guide
Rating
170M7081 1600 A, 700 V
170M7081 1600 A, 700 V
170M7081 1600 A, 700 V
170M7081 1600 A, 700 V
170M7082 2000 A, 700 V
170M7083 2500 A, 700 V
Drive internal Bussmann PN
170M8611
170M8611
170M8611
170M8611
170M8611
170M8611
Bussmann PN
KTK-4
Bussmann PN
KTK-4
–
–
Danfoss A/S © 11/2017 All rights reserved.
Drive internal option
Bussmann PN
170M7082
170M7082
170M7082
170M7082
170M7082
170M7083
Rating
1100 A, 1000 V
1100 A, 1000 V
1100 A, 1000 V
1100 A, 1000 V
1100 A, 1000 V
1100 A, 1000 V
4 A, 600 V
Littelfuse
–
KLK-15
KLK-15
Alternate Siba PN
20 695 32.1600
20 695 32.1600
20 695 32.1600
20 695 32.1600
20 695 32.2000
20 695 32.2500
Alternate Siba PN
20 781 32.1000
20 781 32.1000
20 781 32.1000
20 781 32.1000
20 781 32.1000
20 781 32.1000
Rating
Rating
4 A, 600 V
15 A, 600 V
15 A, 600 V
179
