8.12 F13 Exterior and Terminal Dimensions
8.12.1 F13 Exterior Dimensions
606
(23.9)
2280
(89.7)
2204
(86.8)
8
8
2800 (110.2)
776
776
624
579
(30.6)
(30.6)
(24.6)
(22.8)
Illustration 8.86 Front, Side, and Door Clearance Dimensions for F13
150
Danfoss A/S © 11/2017 All rights reserved.
MG16C302
