8.7 F8 Exterior and Terminal Dimensions
8.7.1 F8 Exterior Dimensions
2280
(89.8)
8
8
Illustration 8.56 Front, Side, and Door Clearance Dimensions for F8
120
®
VLT
HVAC Drive FC 102
800 (31.5)
2204
(86.8)
776
(30.6)
Danfoss A/S © 11/2017 All rights reserved.
606
(23.9)
MG16C302
