4 Options and Accessories Overview

4.1 Fieldbus Devices

This section describes the fieldbus devices that are
®
available with the VLT AutomationDrive FC 361 series.
Using a fieldbus device reduces system cost, delivers faster
and more efficient communication, and provides an easier
user interface. For ordering numbers, refer to
chapter 10.2 Ordering Numbers for Options and Accessories.
4.1.1 VLT ®
PROFIBUS DP-V1 MCA 101
®
The VLT PROFIBUS DP-V1 MCA 101 provides:
•
Wide compatibility, a high level of availability,
support for all major PLC vendors, and compati-
bility with future versions.
•
Fast, efficient communication, transparent instal-
lation, advanced diagnosis, and parameterization
and auto-configuration of process data via a GSD
file.
•
Acyclic parameterization using PROFIBUS DP-V1,
PROFIdrive, or Danfoss FC profile state machines.
4.1.2 VLT ®
PROFINET MCA 120
®
The VLT PROFINET MCA 120 combines the highest
performance with the highest degree of openness. The
option is designed so that many of the features from the
®
VLT PROFIBUS MCA 101 can be reused, minimizing user
effort to migrate PROFINET and securing the investment in
a PLC program.
•
Same PPO types as the VLT
MCA 101 for easy migration to PROFINET.
•
Built-in web server for remote diagnosis and
reading out of basic drive parameters.
•
Supports MRP.
•
Supports DP-V1. Diagnostic allows easy, fast, and
standardized handling of warning and fault
information into the PLC, improving bandwidth in
the system.
•
Implementation in accordance with Conformance
Class B.
MG06K102
Design Guide

4.2 Functional Extensions

This section describes the functional extension options that
are available with the VLT
For ordering numbers, refer to chapter 10.2 Ordering
Numbers for Options and Accessories.
4.2.1 VLT
The VLT
extended number of control inputs and outputs:
4.2.2 VLT
The MCB 102 option offers the possibility to connect
various types of incremental and absolute encoders. The
connected encoder can be used for closed-loop speed
control and closed-loop flux motor control.
The following encoder types are supported:
®
PROFIBUS DP V1
4.2.3 VLT
The MCB 103 option enables connection of a resolver to
provide speed feedback from the motor.
Danfoss A/S © 03/2019 All rights reserved.
®
AutomationDrive FC 361 series.
®
General Purpose I/O Module
MCB 101
®
General Purpose I/O Module MCB 101 offers an
•
3 digital inputs 0–24 V: Logic 0 < 5 V; Logic 1 >
10 V.
•
2 analog inputs 0–10 V: Resolution 10 bits plus
sign.
•
2 digital outputs NPN/PNP push-pull.
•
1 analog output 0/4–20 mA.
•
Spring-loaded connection.
®
Encoder Input MCB 102
•
5 V TTL (RS 422).
•
1VPP SinCos.
®
Resolver Option MCB 103
•
Primary voltage: 2–8 V
rms
•
Primary frequency: 2.0–15 kHz.
•
Primary maximum current: 50 mA rms.
•
Secondary input voltage: 4 V
•
Spring-loaded connection.
.
.
rms
15
4 4
