Danfoss VLT HVAC Drive FC 102 Design Manual page 198

Electrical Installation Con...
1
2
3
10 10
4
L1
L2
L3
PE
5
1 PLC
2
Minimum 16 mm
3 Control cables
4 Minimum 200 mm (7.9 in) between control cables, motor
cables, and mains cables.
5 Mains supply
6 Bare (unpainted) surface
7 Star washers
8 Brake cable (shielded)
9 Motor cable (shielded)
Illustration 10.28 Example of Proper EMC Installation
196
®
VLT HVAC Drive FC 102
2 (6 AWG) equalizing cable
Danfoss A/S © 11/2017 All rights reserved.
90
4
4
PE
10 Mains cable (unshielded)
11 Output contactor
12 Cable insulation stripped
13 Common ground busbar. Follow local and national
requirements for cabinet grounding.
14 Brake resistor
15 Metal box
16 Connection to motor
17 Motor
18 EMC cable gland
6
7
8
9
10
11
12
13
14
15
u
16
v
w
17
18
