Motors with class e protection
When combined with an ATEX approved PTC monitoring
device like the VLT
lation does not need an individual approval from an
approbated organization.
Motors with class d/e protection
The motor itself has an e ignition protection class, while
the motor cabling and connection environment is in
compliance with the d classification. To attenuate the high
peak voltage, use a sine-wave filter at the drive output.
When using a drive in a potentially explosive
atmosphere, use the following:
•
Motors with ignition protection class d or e.
•
PTC temperature sensor to monitor the motor
temperature.
•
Short motor cables.
•
Sine-wave output filters when shielded motor
cables are not used.
NOTICE
MOTOR THERMISTOR SENSOR MONITORING
Drives with the VLT
9 9
option are PTB-certified for potentially explosive
atmospheres.

9.4 Mounting Configurations

Table 9.1 lists the available mounting configurations for
each enclosure. For specific panel/wall mounting or
pedestal mounting installation instructions, see the
operating guide. See also chapter 8 Exterior and Terminal
Dimensions.
NOTICE
Improper mounting can result in overheating and
reduced performance.
Enclosure
E1
E2
F1
F2
F3
F4
F8
F9
F10
F11
F12
F13
Table 9.1 Mounting Configurations
160
VLT
®
PTC Thermistor Card MCB 112, instal-
®
PTC Thermistor Card MCB 112
Panel/wall Pedestal mounting
mounting (Standalone)
– X
X –
– X
– X
– X
– X
– X
– X
– X
– X
– X
– X
Danfoss A/S © 11/2017 All rights reserved.
®
HVAC Drive FC 102
Mounting considerations:
•
Locate the unit as near to the motor as possible.
See chapter 7.6 Cable Specifications for the
maximum motor cable length.
•
Ensure unit stability by mounting the unit to a
solid surface.
•
Ensure that the strength of the mounting location
supports the unit weight.
•
Ensure that there is enough space around the
unit for proper cooling. Refer to
chapter 9.5 Cooling.
•
Ensure enough access to open the door.
•
Ensure cable entry from the bottom.
1) For non-typical installation, contact the factory.
1)
MG16C302
