Exterior and Terminal Dimen...
535 (21.1)
8
8
1
Mains side
Illustration 8.20 Gland Plate Dimensions for F1
84
VLT
668 (26.3)
38 (1.5)
460 (18.1)
216 (8.6)
282 (11.1)
533 (21.0)
36 (1.4)
596 (23.4)
Danfoss A/S © 11/2017 All rights reserved.
®
HVAC Drive FC 102
1329 (52.3)
2
Motor side
1
593 (23.3)
200 (7.9)
258 (10.2)
36 (1.4)
MG16C302
