8.3 F1 Exterior and Terminal Dimensions
8.3.1 F1 Exterior Dimensions
2280
(89.7)
578
(22.8)
Illustration 8.19 Front, Side, and Door Clearance Dimensions for F1
MG16C302
Design Guide
1400 (55.2)
Danfoss A/S © 11/2017 All rights reserved.
2204
(86.8)
776
(30.6)
606
(23.9)
83
8
8
