8 Exterior and Terminal Dimensions
8.1 E1 Exterior and Terminal Dimensions
8.1.1 E1 Exterior Dimensions
2000
(78.7)
748
(29.5)
Illustration 8.1 Front, Side, and Door Clearance Dimensions for E1
MG16C302
Design Guide
600 (23.6)
579
(22.8)
Danfoss A/S © 11/2017 All rights reserved.
494 (19.4)
538 (21.2)
8
8
67
