5.3.2 Using a Drive for Better Control
If a drive is used for controlling the flow or pressure of a
system, improved control is obtained. A drive can vary the
speed of the fan or pump, obtaining variable control of
flow and pressure utilizing the built-in PID control.
Furthermore, a drive can quickly adapt the speed of the
fan or pump to new flow or pressure conditions in the
system.
Cos φ compensation
®
HVAC Drive has a cos φ of 1 and
Typically, the VLT
provides power factor correction for the cos φ of the
motor, which means there is no need to make allowance
for the cos φ of the motor when sizing the power factor
correction unit.
Star/delta starter or soft starter not required
When larger motors are started, it is necessary in many
countries to use equipment that limits the start-up current.
In more traditional systems, a star/delta starter or soft
starter is widely used. Such motor starters are not required
if a drive is used. As illustrated in Illustration 5.13, a drive
does not consume more than rated current.
