8.11 F12 Exterior and Terminal Dimensions
8.11.1 F12 Exterior Dimensions
2280
(89.7)
8
8
776
(30.6)
Illustration 8.80 Front, Side, and Door Clearance Dimensions for F12
144
®
VLT
HVAC Drive FC 102
2000 (78.8)
624
(24.6)
Danfoss A/S © 11/2017 All rights reserved.
2204
(86.8)
579
(22.8)
606
(23.9)
MG16C302
