NOTE: For more information about how to hot swap NVMe PCIe SSD U.2 device, see the
SSD User's Guide at Dell.com/support > Browse all Products > Data Center Infrastructure > Storage Adapters &
Controllers > Dell PowerEdge Express Flash NVMe PCIe SSD > Documentation > Manuals and Documents.
Backplane:
• 8 x 3.5-inch SAS, SATA drives
• 24 x 2.5-inch SAS, SATA drives
• 24 x 2.5-inch NVMe drives
• 12 x 3.5-inch SAS, SATA drives and 2 x 3.5-inch SAS, SATA drives
• 12 x 2.5-inch SAS, SATA drives and 12 x 2.5-inch NVMe drives
• 8 x 2.5-inch SAS, SATA drives and 16 x 2.5-inch NVMe drives

Optical drives

The PowerEdge R7515 system supports the following optical drives:
Table 56. Supported optical drive type
Supported drive type
Dedicated SATA DVD-ROM drive or DVD +/-RW drive

Ports and connectors specifications

USB ports specifications

Table 57. PowerEdge R7515 system USB specifications
Front
USB port type No. of ports
USB 2.0-compliant Two
port
Micro USB 2.0- One
compliant port for
iDRAC Direct
NOTE: The micro USB 2.0 compliant port can only be used as an iDRAC Direct or a management port.

LOM Riser card specifications

The PowerEdge R7515 system supports up to two 10/100/1000 Mbps Network Interface Controller (NIC) ports that are located on the
back panel. The system also supports LAN on Motherboard (LOM) on an optional riser card.
You can install one LOM riser card. The supported LOM riser options are:
• 2 x 1 Gb Base-T
• 2 x 10 Gb Base-T
• 2 x 10 Gb SFP+
• 2 x 25 Gb SFP+
NOTE:
• You can install up to four PCIe add-on NIC cards.
• For information about Linux network performance settings, see the
Processor Based Servers white paper at
150 Technical specifications
Supported number of drives
One
Rear
USB port type
USB 3.0-compliant Two
ports
AMD.com
No. of ports USB port type
Internal USB 3.0-
compliant port
Linux Network Tuning Guide for AMD EPYC
Dell Express Flash NVMe PCIe
Internal
No. of ports
One
