U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Main Menu=>Basic=>
Link Status
Enter 2 at the Basic Menu. The Link Status Menu appears. This menu displays current link
status. Link status parameters include...
Main Menu=>Basic=>
WAN Setup
Enter 3 at the Basic Menu. The WAN Setup Menu appears. This menu allows you list, configure,
or delete ATM PVCs. Each option takes you to another screen.
file:///P|/T_WRITER/Documentation/Released/9003.../9003%20(Guiness)%20prac%20template/tquicks.htm (5 of 42) [11/6/2002 8:58:14 AM]
Link Status Parameters
Status Term
ADSL Line Status
ADSL Standard
UpStream
DownStream
Attenuation
SNR Margin
HEC Count
Firmware
15 min ES Counter
CRC Errors
1 day ES Counter
Meaning
Displays the current ADSL line status
Displays the ADSL standard within the
current configuration. The standards are:
MULTI, T1.413, G.dmt, and G.Lite.
Displays the upstream data rate, as
negotiated by DSL link (KB/s)
Displays the downstream data rate, as
negotiated by DSL link (KB/s)
Displays the current attenuation in decibels
Displays the current SNR margin in decibels
Displays the number of ATM cells received
with errors since start of link.
Displays the version number of the firmware
Displays the number of errors per second
for the current 15-minute period
Displays the number of cyclical redundancy
check errors per second since training
Displays the number of errors per second
for the current day
