U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
• CONFIGURATION EXAMPLE
Setting Up PPPoA
Configuration Description
Dial-up Internet connections commonly use Point-to-Point Protocol (PPP). PPPoA is a method for
running the PPP protocol over ATM. PPPoA...
file:///P|/T_WRITER/Documentation/Released/900...%20(Guiness)%20prac%20template/configexamp.htm (10 of 33) [11/6/2002 9:00:35 AM]
15. Verify your Default
Gateway IP address setting.
(See Figure 4.)
16. Verify that you've
enabled the DNS Relay
function. (See Figure 4.)
17. Click DHCP.
18. Verify your DHCP
entries. (See Figure 5.)
19. Verify that the server is
running. (See Figure 5.)
Figure 5
