U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
file:///P|/T_WRITER/Documentation/Released/900...ide/9003%20(Guiness)%20prac%20template/wui.htm (22 of 55) [11/6/2002 8:53:37 AM]
Spanning Tree - MAC Filters
The MAC address is a unique serial number burned into Ethernet adapters. This address
distinguishes the network card from others. MAC Filters allow or reject WAN access for
specific machines.
•List of MAC Address Filters. Known MAC addresses and the ports on which the router
learned the addresses.
To view current filter states, click Parameters. The following screen appears...
To close the screen, click OK.
To add a static MAC address to the table, click Add. The following screen appears...
