U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Contents:
Summary
file:///P|/T_WRITER/Documentation/Released/900...ide/9003%20(Guiness)%20prac%20template/wui.htm (1 of 55) [11/6/2002 8:53:37 AM]
Ethernet/USB Router User Guide
Windows 95, 98, NT 4.0, Me, 2000, XP or later, Mac
and Linux
Web User Interface
Overview
The Web User Interface (WUI) is one of three router user interfaces. The other interfaces
are the Terminal User Interface (TUI) and Command Line Interface (CLI). Each interface
allows you to set up, modify, and view router configuration variables and operational data.
The Web User Interface is a system of graphical menus. Menu pages control router
parameters and provide information about them. The WUI organizes these router
parameters into six topics. Here are the six topics, in the order that the WUI displays them...
Quick Setup
Service Provider
Settings
Network Settings
This part of the manual discusses all but the Quick Setup topic. You'll find information on
using the Quick Setup feature in the Quick Installation Guide.
This manual begins topic discussions with a picture of the top-level menu screen. A
description of screen terms and procedures follows each screen shot. Either text or a table
defines screen variables. Afterward, summarized, step-by-step procedures often follow.
Selecting Topics. When you look at a menu page, notice the divider tabs at the very top of
the page. You can access any of the six router configuration and information topics by
clicking on its tab. The graphic below portrays the six divider tabs as they appear on a
menu.
Divider Tabs •
™
Firewall Settings
Tools
Statistics
ADSL
