4. Verify that you've selected
Multi Mode. (See Figure 2.)
5. Click WAN Setup.
6. Verify that only the Routed
configuration appears on the
Current ATM PVC List. (This is
the list on the bottom of the
screen. See Figure 3.)
7. See the Current ATM PVC
List at the bottom of the screen
(Figure 3). On this list, verify your
VPI and VCI settings.
8. On the Current ATM PVC
List, see "Encap." Verify your
Encapsulation Mode settings.
(See Figure 3.)
9. On the Current ATM PVC
List, see "NAT." Verify that NAT
is "On." (See Figure 3.)
10. Click the Network tab at
the top of the window.
11. Click DNS Relay.
12. Verify your Domain Name
setting. (See Figure 4.)
Figure 2
Figure 3
