U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Accessing the Terminal User Interface
To access the Terminal User Interface, follow these steps...
1.
2.
3.
• Terminal Type: VT-100
• Bits Per Second: 9600
• Data Bits: 8
4.
5.
6.
default password is 12345.
Click for PDF
file:///P|/T_WRITER/Documentation/Released/9003.../9003%20(Guiness)%20prac%20template/tquicks.htm (2 of 42) [11/6/2002 8:58:14 AM]
Connect a console cable between a computer and the router.
Launch a terminal emulation program.
Configure the terminal emulation program as follows...
Turn on the router. Configuration messages appear as the router boots up.
Allow the default configuration to load.
When prompted, type in the User Name and Password. The default user name is Root. The
Terminal User Interface Map
• Parity: None
• Stop Bits: 1
• Flow Control: None
