U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Verify Setup
file:///P|/T_WRITER/Documentation/Released/900...%20(Guiness)%20prac%20template/configexamp.htm (8 of 33) [11/6/2002 9:00:35 AM]
23. On the DNS Relay line, select Enable from the dropdown menu.
24. Click Apply.
25. Click the Tools tab at the top of the window.
26. Click Save & Restart.
27. Click Save.
28. Click Restart.
1. Open the SureConnect
Web User Interface (WUI).
2. Click the Service Provider
Settings tab. This tab is on the
top of the screen. (See Figure 1.)
3. Click ADSL Standard.
(See Figure 1.)
4. Verify that you've selected
Multi Mode. (See Figure 2.)
5. Click WAN Setup.
Figure 1
Figure 2
