US Robotics SureConnect U.S. Robotics SureConnect ADSL Ethernet/USB Router User Manual page 39

U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
file:///P|/T_WRITER/Documentation/Released/900...ide/9003%20(Guiness)%20prac%20template/wui.htm (37 of 55) [11/6/2002 8:53:38 AM]
Term
Port Proxy port.
Priority Priority of the policy you're creating. Options range from 0
to 65,535.
User Name A configured user in the router's internal database. You
must configure users through the Access Control Menu.
Application Type HTTP application file type (MIME) to filter or proxy.
Options are... •application (all), •image (all), •video (all),
•audio (all), •application/octet-stream, •audio/x-wav,
•audio/x-mpeg, •image/jpeg, •video/mpeg.
Destination Address Destination IP address of the FTP or HTTP server on the
WAN.
Source Range Local IP address range that the rule applies to. "From" is
the first IP address in the range. "To" is the last IP
address in the range.
Domain Name Address of an Internet site to filter.
Day From/To Set the effective start (From) day and time for the policy.
Set the effective stop (To) day and time for the policy.
Proxy Parameters
Definition
