U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Verify Setup
file:///P|/T_WRITER/Documentation/Released/900...%20(Guiness)%20prac%20template/configexamp.htm (3 of 33) [11/6/2002 9:00:35 AM]
10.
Enter VPI and VCI values.
11. Select your desired encapsulation mode. Your choices are: LLC/SNAP and VC Multiplexing.
12. At Network Settings, be sure that Enable NAPT and Enable DHCP remain unselected.
13. Click Add.
14. Click the Tools tab at the top of the window.
15. Click Save & Restart.
16. Click Save.
17. Click Restart.
1. Open the SureConnect
Web User Interface (WUI).
2. Click the Service Provider
Settings tab. This tab is on the
top of the screen. (See Figure 1.)
3. Click ADSL Standard.
(See Figure 1.)
4. Verify that you've selected
Multi Mode. (See Figure 2.)
5. Click WAN Setup.
6. See the Current ATM
PVC List at the bottom of the
screen (Figure 3). On this list,
verify your VPI and VCI
settings.
Figure 1
Figure 2
