U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
With PPPoA, the router achieves IP routing with Network Address Translation (NAT) for the LAN. The
PPPoA-enabled router also supports dynamic IP address assignment to local network nodes. With
dynamic assignment, the router acts as a DHCP server.
Setup
file:///P|/T_WRITER/Documentation/Released/900...%20(Guiness)%20prac%20template/configexamp.htm (11 of 33) [11/6/2002 9:00:35 AM]
Allows ISPs to provide billing and access control similar to what dial up systems offer.
Provides session authentication using either Password Authentication Protocol (PAP) or
Challenge Handshake Authentication Protocol (CHAP).
Permits router signals to easily negotiate link and network parameters between the router
and ISP.
1.
Open the SureConnect Web User Interface (WUI). This example employs the
Web User Interface. You can set up the Network Model with any of the router's three
interfaces. The other two interfaces are the Terminal User Interface (TUI) and the
Command-Line Interface (CLI). In any case, succeeding steps are similar.
2. Click ADSL Standard. The ADSL Standard Window opens.
3. Select the ADSL protocol that you'll use. For most users, Multi Mode is the right
choice.
4. Click Apply.
