U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide

• CONFIGURATION EXAMPLE

Setting Up MER

Configuration Description

file:///P|/T_WRITER/Documentation/Released/900...%20(Guiness)%20prac%20template/configexamp.htm (4 of 33) [11/6/2002 9:00:35 AM]
7. On the Current ATM
PVC List, see "Encap." Verify
your Encapsulation Mode
settings. (See Figure 3.)
8. See the Current ATM
PVC List. Verify that only the
RFC Bridged configuration
appears there. (See Figure 3.)
9. Click Bridging.
10. Verify your bridging
entries. (See Figure 4.)
Figure 3
Figure 4
