U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Configuration Description
When you use RFC1483 Routing, the router encapsulates IP packets over the ATM virtual circuit.
This circuit connects the router and the Internet service provider (ISP). In this configuration, routers ...
Setup
file:///P|/T_WRITER/Documentation/Released/900...%20(Guiness)%20prac%20template/configexamp.htm (21 of 33) [11/6/2002 9:00:35 AM]
Segment LANs to balance traffic within workgroups
Filter traffic for security purposes and policy management
Connect remote offices at the edge of the network
1. Open the SureConnect Web User Interface (WUI). This example employs the Web User Interface. You can set up
the Network Model with any of the router's three interfaces. The other two interfaces are the Terminal User
Interface (TUI) and the Command-Line Interface (CLI). In any case, succeeding steps are similar.
2. Click ADSL Standard. The ADSL Standard Window opens.
3. Select the ADSL protocol that you'll use. For most users, Multi Mode is the right choice.
4. Click Apply.
5. Click WAN Setup. The WAN Setup Window opens.
