U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Enter 10 at the Advanced Menu. The Statistics Menu appears. This menu provides the following
options...
Interface Parameters
file:///P|/T_WRITER/Documentation/Released/900...9003%20(Guiness)%20prac%20template/tquicks.htm (40 of 42) [11/6/2002 8:58:14 AM]
Interface. Enter 1 at the Statistics Menu. The Interface Menu appears. This menu
displays interface statistics. The table below defines interface parameters.
Interface Term
Interface Name
Admin Status
Octets In
Unicast PktsIn
Broadcast PktsIn
Discards In
Errors In
Octets Out
Unicast PktsOut
Broadcast PktsOut
Discards Out
Errors Out
TCP-IP. Enter 2 at the Statistics Menu. The Interface Menu appears. This menu displays
TCP/IP statistics.
DHCP-Lease. Enter 3 at the Statistics Menu. The DHCP Lease Menu appears. This menu
displays DHCP statistics. With no active DHCP leases, the list is empty.
AAL5. Enter 4 at the Statistics Menu. The AAL5 Menu appears. This menu displays ATM
AAL5 statistics.
SNDCP. Enter 5 at the Statistics Menu. The SNDCP Menu appears. This menu displays
packet information for the permanent virtual circuit (PVC). The system organizes the list
by encapsulation method.
Bridge. Enter 6 at the Statistics Menu. The Bridge Menu appears. This menu displays
bridge statistics.
Meaning
Name of the interface
Indicates whether the interface is up or
down
Number of received octets (in bytes)
Number of received unicast packets
Number of received broadcast packets
Number of received and discarded packets
Number of received errors
Number of transmitted octets (in bytes)
Number of transmitted unicast packets
Number of transmitted broadcast packets
Number of transmitted and discarded
packets
Number of transmitted errors
