U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
• CONFIGURATION EXAMPLE
Setting Up RFC1483 Routing without NAT
file:///P|/T_WRITER/Documentation/Released/900...%20(Guiness)%20prac%20template/configexamp.htm (20 of 33) [11/6/2002 9:00:35 AM]
11. In the PPPoE box, verify
for your dialing mode
selection. For most users,
direct is the right choice. (See
Figure 3.)
12. In the PPPoE box, verify
your desired Idle Timeout
value. (See Figure 3.)
13. In the PPPoE box, find
the authentication protocol.
Verify that your ISP uses this
protocol. (See Figure 3.)
14. Click the Network tab at the
top of the window.
15. Click DHCP.
16. Verify your DHCP setting.
(See Figure 4.)
17. Verify that the DHCP
server started. (See Figure 4.)
Figure 4
