U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
Configure Service Provider Settings
In the Service Provider Settings/WAN Setup screen, enter in the values obtained from your
ISP. See the ISP Settings Table at the end of this Web page for popular ISP settings.
(Settings may vary from the table listing. Check with your ISP.) If you don't find your ISP on
the table, call your ISP to obtain the correct settings.
file:///P|/T_WRITER/Documentation/Released/9003%20(Guinness)/User%20Guide/9003%20(Guiness)%20prac%20template/installa.htm (18 of 25) [11/6/2002 8:55:05 AM]
1. See the Current ATM PVC List at the bottom of the screen. On this list, delete any
connection type that you don't need.
2. Select the connection type recommended by your ISP. Choose either RFC1483 bridged
mode, RFC 1483 routed mode, PPPoE mode, PPPoA mode, or MER mode. Some
connection types may require additional information, such as IP address or username
and password.
3. At the top of the WAN Screen, fill in the VPI and VCI values.
4. Select Encapsulation. Click either LLC/SNAP or VC Multiplexing.
5. If appropriate, select Enable NAPT.
6. If appropriate, select Enable DHCP.
7. Click Add.
8. To continue, click Next in the lower right corner of the screen.
