U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
units of cells per second.
-avg <value> Defines the maximum sustainable/average rate a user can send cells to the network.
It is expressed in cells per second. This specifies the bandwidth utilization. This value must always
be less than or equal to the Peak Cell Rate (see -pcr option).
-mbs <value> Maximum number of cells the user can send at the peak rate in a burst, within the
sustainable rate.
-cdvt <value> Constrains the number of cells the user can send to the network at the maximum
line rate. It is expressed in microseconds.
Examples:
vcadd 0 38 cbr aal2 -o -peak 1600 -mbs 25 -cdvt 50000
The following creates a PVC (vpi - 0,vci - 38). Service class is cbr (Constant Bit Rate) and
encapsulation as aal2 (for voice). The traffic descriptors are set for peak cell rate of 1600kbps,
burst size of 25 cells, and cell delay variation of 50000 microseconds.
vcadd 0 39 ubr aal5
The following creates a PVC (vpi=0, vci=39). Service class is ubr (Unspecified Bit Rate) and
encapsulation is aal5 (for data).
1.24.2 deletevc
deletevc <vpi> <vci>
Deletes the specified PVC. The PVC is identified by the vpi / vci values.
Example:
deletevc 0 39
Deletes a PVC with vpi=0 and vci=39.
1.24.3 showatmconn
showatmconn
Lists the existing PVCs.
Example:
showatmconn
