Policy Parameters
On the Firewall Configuration page, notice the header "Policy Parameters." The Policy
Parameters menu presents you with the following onscreen options ...
Precedence. Priority of the policy that you're creating. Options range from 0 to
65,535. The lower precedence number takes priority.
Src IP Address. Data source. Enter either a specific IP address or network
address.
Src Net Mask. Subnet Mask for the data's network source. Options range from
/12 (255.240.0.0) to /32 (255.255.255.255).
Dest IP Address. Data destination. Enter either a specific IP address or network
address.
Dest Net Mask. Subnet Mask for the data's network destination. Options range
from /12 (255.240.0.0) to /32 (255.255.255.255).
