U.S. Robotics SureConnect ADSL Ethernet/USB Router User Guide
§ Vpi [0-255]
§ Vci [0-65,535]
§ Interface Name [ atm [0-7] ]
§ Encapsulation Type [aa15]
After you complete your configuration, proceed to the Basic Menu and enter 8. The Save &
Reboot Menu appears. From this menu, save your changes and reboot the router.
§ Vpi [0-255]
§ Vci [0-65,535]
§ Interface Name [ ATM [0-7] ]
After you complete your configuration, proceed to the Basic Menu and enter 8. The Save &
Reboot Menu appears. From this menu, save your changes and reboot the router.
Main Menu=>Advanced=>SNDCP=>
file:///P|/T_WRITER/Documentation/Released/900...9003%20(Guiness)%20prac%20template/tquicks.htm (30 of 42) [11/6/2002 8:58:14 AM]
IPoA. Enter 1 at the SNDCP Menu. The IPoA Menu appears. This menu allows you to list
IPoA variables. You can also configure IPoA variables by VCC and interface. To add IPoA
variables, set these options...
Routed. Enter 2 at the SNDCP Menu. The Routed Menu appears. This menu allows you
to list routed variables. You can also configure routed variables by setting these options...
§ Default PVC [Y/N]
§ Next Hop IP Address
§ Status [enable/disable]
§ Encapsulation Type [11c/vc]
§ Status [enable/disable]
