Krone Swadro 1010 Operating Instructions Manual page 6

List of contents
4 Handling the swather when in use ................................................. IV -1
4.1 Mounting on the tractor .......................................................................................... IV -1
4.2 Overload protection feature ................................................................................... IV -1
4.3 Converting from transport to working position ........................................................ IV -2
4.3.1 Lowering the rotor arms ........................................................................................ IV -2
4.3.2 Folding the tine arms into working position ............................................................. IV -3
4.3.3 Moving the external guard bars into working position ............................................. IV -4
4.3.4 Swaths without a swath cloth ................................................................................. IV -5
4.4.1 Moving the external guard bars into transport position ........................................... IV -5
4.4 Conversion from working to transport position ....................................................... IV -5
4.4.2 Folding the tine arms into transport position ........................................................... IV -7
4.4.3 Lifting the rotor arms ............................................................................................. IV -8
4.4.4 Securing the tine tips (transport position and parked swather) .............................. IV -9
4.4.5 Driving in sloping .................................................................................................... IV -9
4.5 Removal from tractor ........................................................................................... IV -10
5 Basic setting ...................................................................................... V -1
5.1 Height of the tractor lower link arms ....................................................................... V -1
5.2 Setting the Operating Width .................................................................................... V -2
5.3 Setting the lateral inclination of the swather disk chassis ........................................ V -3
5.3.1 Setting of the rotor running gear on the front rotor .................................................. V -3
5.3.2 Setting of the rotor running gear on the centre and rear right rotors ....................... V -3
5.4 Adjusting the Direction of Travel .............................................................................. V -4
5.4.1 Adjusting the track .................................................................................................. V -4
5.5 Travel speed and drive r.p.m. ................................................................................. V -4
5.6 Adjustable throttles ................................................................................................. V -5
5.7 Setting of the scraper ............................................................................................. V -6
5.8 Adjusting the Compensation Springs on the Rear Rotor .......................................... V -6
5.9 Adjusting the Ground Pressure on the Rear Rotor Running Gear ........................... V -7
6 Care and maintenance .................................................................... VI - 1
6.1 Special safety instructions ..................................................................................... VI - 1
6.2 General instructions .............................................................................................. VI - 1
6.3 Tyres ................................................................................................................... VI - 2
6.3.1 Air pressure .......................................................................................................... VI - 2
6.3.2 Wheel fixings ......................................................................................................... VI - 2
6.3.3 Frame flanges ....................................................................................................... VI - 3
6.4 Replacing the tine arms (in case of repair) ........................................................... VI - 3
6.5 Replacing the hydraulic hose lines ........................................................................ VI - 3
7 Lubrication ........................................................................................ VI -1
7.1 Universal drive shaft ............................................................................................... VI -1
7.2 Bearings on the swather ........................................................................................ VI -1
7.3 Lubricant quantities and designations for the gearboxes ........................................ VI -2
7.4 Pass-through gearbox ............................................................................................ VI -2
7.5 Front drive gear ..................................................................................................... VI -3
7.6 Rear drive gear ...................................................................................................... VI -4
2
