Krone Swadro TC 680 Original Operating Instructions
  1. Manuals
  2. Brands
  3. Krone Manuals
  4. Farm Equipment
  5. Swadro TC 680
  6. Original operating instructions

Krone Swadro TC 680 Original Operating Instructions

Rotary rake
Hide thumbs Also See for Swadro TC 680:
Table of Contents

Advertisement

Quick Links

Download this manual
Rotary Rake
Swadro TC 680
Swadro TC 760
(from serial no.: 913 038)
Order no.: 150 000 287 02 en
20.05.2015

Advertisement

Table of Contents
loading

Related Manuals for Krone Swadro TC 680

Summary of Contents for Krone Swadro TC 680

  • Page 1 Rotary Rake Swadro TC 680 Swadro TC 760 (from serial no.: 913 038) Order no.: 150 000 287 02 en 20.05.2015...
  • Page 2 Rotary rake KRONE type / types: Swadro TC 680; Swadro TC 760 to which this declaration refers is in compliance with the relevant provisions of EC Directive 2006/42/EC (machines) The signing managing director is authorised to compile the technical documents.

  • Page 3: Table Of Contents

    Table of Contents Pos: 3 /Layout Module /Inhaltsverzeichnis @ 0\mod_1196861555655_78.docx @ 15165 @ 1 @ 1 Table of Contents     Table of Contents ........................... 3     Foreword ..............................6     To this Document ........................... 7     Validity ..............................
  • Page 4 Table of Contents     Information Required for Questions and Orders ................30     5.3.1 Contact ............................30     Overload protection .......................... 31     Technical Data of the Machine ......................32     Technical data ..........................32  ...
  • Page 5 Table of Contents     11.9 Raising Outrigger Arms into Transport Position ................71     11.9.1 For design without single-rotor lifting mechanism ..............71     11.9.2 For design with hydraulic single-rotor lifting mechanism ............72     11.9.3 In Case of Electro-Hydraulic Single-Rotor Lifting Mechanism Design ........

  • Page 6: Foreword

    Pos: 5.2 /BA/Vorwort/Schwader/Verehrter Kunde Schwader @ 1\mod_1202129116819_78.docx @ 57456 @ @ 1 Dear Customer, By purchasing your rotary rake, you have acquired a quality product from KRONE. We are grateful for the confidence you have invested in us in buying this machine.

  • Page 7: To This Document

    Validity These operating instructions apply to rotary rakes of the series: Swadro TC 680, Swadro TC 760 Pos: 9 /BA/Sicherheit/6. Überarbeitete Warnhinweise/Kennzeichnung von Hinweisen in der Betriebsanleitung Einführungstext (2012-07-27 09:59:06) @ 0\mod_1195637804826_78.docx @ 1098 @ 2 @ 1 Identifying Symbols in the Operating Instructions...

  • Page 8: Means Of Representation

    To this Document Pos: 14 /Überschriften/Überschriften 2/A-E/Darstellungsmittel @ 188\mod_1380549164047_78.docx @ 1614423 @ 2 @ 1 Means of representation Pos: 15 /BA/Zu diesem DokumentDarstellungsmittel_ohne Hinweis und Warnung (2014-12-10 12:04:03) @ 304\mod_1414563113176_78.docx @ 2362425 @ @ 1 In these operating instructions, the following means of representation are used: Action steps One point () indicates an action step you have to perform, as for example: •...

  • Page 9: Safety

    Safety Pos: 17.1 /Überschriften/Überschriften 1/P-T/Sicherheit @ 0\mod_1195566748646_78.docx @ 635 @ 1 @ 1 Safety Pos: 17.2 /Überschriften/Überschriften 2/U-Z/Verwendungszweck @ 1\mod_1201707246738_78.docx @ 54055 @ 2 @ 1 Purpose of Use Pos: 17.3 /BA/Einleitung/Schwader/Verwendungszweck Schwader KAT I und KAT II am Heck. @ 1\mod_1202129727897_78.docx @ 57517 @ @ 1 The rotary rake is used for swathing of cut crops.

  • Page 10: Personnel Qualification

    Safety Pos: 17.9.6 /Überschriften/Überschriften 3/P-T/PPersonalqualifikation @ 187\mod_1380011550253_78.docx @ 1606703 @ 3 @ 1 4.4.2 Personnel qualification Pos: 17.9.7 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Personalqualifikation @ 176\mod_1372840611484_78.docx @ 1505639 @ @ 1 If the machine is not used properly, people may be seriously injured or killed. To avoid accidents, each person who works with the machine must satisfy the following minimum requirements: –...

  • Page 11: Additional Equipment And Spare Parts

    Safety Pos: 17.9.15 /Überschriften/Überschriften 3/U-Z/Zusatzausrüstungen und Ersatzteile @ 187\mod_1380012000801_78.docx @ 1606819 @ 3 @ 1 4.4.6 Additional equipment and spare parts Pos: 17.9.16 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Zusatzausrüstungen und Ersatzteile @ 176\mod_1372844184073_78.docx @ 1506194 @ @ 1 Additional equipment and spare parts, which do not comply with the requirements of the manufacturer, may impair the operational safety of the machine and cause accidents.
  • Page 12 Safety Pos: 17.9.24 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Betriebssicherheit - Gefahr durch Schäden an der Maschine Wender @ 276\mod_1404743734630_78.docx @ 2075019 @ @ 1 Danger resulting from damage to the machine Damage to the machine may impair the operational safety of the machine and cause accidents. As a result, people may be seriously injured or killed.

  • Page 13: Danger Zones

    Safety Pos: 17.9.27 /Überschriften/Überschriften 3/F-J/Gefahrenbereiche @ 187\mod_1380012427290_78.docx @ 1606906 @ 3 @ 1 4.4.9 Danger zones Pos: 17.9.28 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Gefahrenbereiche rund um Anhängegerät, Anbaugerät o. Anhänger T1 @ 176\mod_1372858104099_78.docx @ 1506686 @ @ 1 Danger zones on the tractor and the machine The area around the tractor and the machine is a danger zone.
  • Page 14 Safety Pos: 17.9.31 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Gefahrenbereich zwischen Traktor und Maschine @ 176\mod_1372930525648_78.docx @ 1507354 @ @ 1 Danger zone between tractor and machine People standing between the tractor and machine may be seriously injured or killed if the tractor rolls away or by machine movements: •...

  • Page 15: Keeping Safety Devices Functional

    Safety Pos: 17.9.37 /Überschriften/Überschriften 3/P-T/SSchutzvorrichtungen funktionsfähig halten @ 187\mod_1380021062004_78.docx @ 1607105 @ 3 @ 1 4.4.10 Keeping safety devices functional Pos: 17.9.38 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Schutzvorrichtungen funktionsfähig halten @ 176\mod_1373004721530_78.docx @ 1508355 @ @ 1 If safety devices are missing or damaged, people may be seriously injured or killed by moving machine parts.

  • Page 16: Safety Signs On The Machine

    Safety Pos: 17.9.43 /Überschriften/Überschriften 3/P-T/SSicherheitskennzeichnungen an der Maschine @ 187\mod_1380021311979_78.docx @ 1607165 @ 3 @ 1 4.4.12 Safety signs on the machine Pos: 17.9.44 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Sicherheitskennzeichnungen an der Maschine @ 176\mod_1373014574852_78.docx @ 1508510 @ @ 1 Safety stickers on the machine warn of hazards in danger areas and are an important component of the safety equipment of the machine.

  • Page 17: Parking The Machine Safely

    Safety Pos: 17.9.50 /Überschriften/Überschriften 3/K-O/Maschine sicher abstellen @ 187\mod_1380021652951_78.docx @ 1607221 @ 3 @ 1 4.4.14 Parking the machine safely Pos: 17.9.51 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Maschine sicher abstellen @ 176\mod_1373262472095_78.docx @ 1509055 @ @ 1 The parked machine may overturn. People may be crushed and killed. •...

  • Page 18: Sources Of Danger On The Machine

    Safety Pos: 17.9.57 /Überschriften/Überschriften 3/F-J/Gefahrenquellen an der Maschine @ 187\mod_1380022841201_78.docx @ 1607417 @ 3 @ 1 4.4.16 Sources of danger on the machine Pos: 17.9.58 /BA/Sicherheit/1. Grundlegende Sicherheitshinweise/Gefahrenquellen - Lärm (Traktor und Maschine) Verweis auf Technische Daten @ 321\mod_1424859929013_78.docx @ 2481250 @ @ 1 Noise may lead to health problems When working with the machine for a longer time, serious health damage may result such as hearing loss, deafness or tinnitus.

  • Page 19: Dangers Associated With Certain Activities: Work On The Machine

    Improper welding work will endanger the operational safety of the machine. As a result, accidents may occur and people may be seriously injured or killed. • Before performing welding work on the machine, obtain the consent of KRONE customer service and, if required, identify alternatives. •...

  • Page 20: Dangers Associated With Certain Activities: Working On Wheels And Tyres

    The fitting of wheels and tyres requires adequate knowledge and approved tools. • If there is a lack of knowledge, have the wheels and tyres fitted by the KRONE dealer or by a qualified tyre service. •...

  • Page 21: Safety Routines

    Safety Pos: 17.11.1 /Überschriften/Überschriften 2/P-T/Sicherheitsroutinen @ 187\mod_1380089318480_78.docx @ 1608182 @ 2 @ 1 Safety routines Pos: 17.11.2 /Überschriften/Überschriften 3/K-O/Maschine stillsetzen und sichern @ 190\mod_1381323544614_78.docx @ 1624780 @ 3 @ 1 4.5.1 Stopping and securing the machine Pos: 17.11.3 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine stillsetzen und sichern - mit und ohne Unterlegkeilen und ohne Feststellbremse @ 244\mod_1395816937956_78.docx @ 1909874 @ @ 1 WARNING! Risk of injury due to movement of the machine or machine parts If the machine has not been shut down, the machine or machine parts may move...

  • Page 22: Coupling The Machine Safely

    Safety Pos: 17.11.7 /Überschriften/Überschriften 3/K-O/Maschine sicher ankuppeln @ 274\mod_1404282415732_78.docx @ 2062014 @ 3 @ 1 4.5.3 Coupling the machine safely Pos: 17.11.8 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine an den Traktor ankuppeln (Wender) @ 277\mod_1404811947096_78.docx @ 2077871 @ @ 1 WARNING! Risk of injury while hitching the machine While hitching the machine to the tractor, the machine or machine parts may move unintentionally.

  • Page 23: Preparing The Machine For Repair, Maintenance And Adjustment Work

    Safety Pos: 17.11.12 /Überschriften/Überschriften 3/K-O/Maschine für Instandhaltungs-, Reparatur-, Wartungs- und Einstellarbeiten vorbereiten @ 274\mod_1404283183227_78.docx @ 2062418 @ 3 @ 1 4.5.5 Preparing the machine for repair, maintenance and adjustment work Pos: 17.11.13 /BA/Sicherheit/3. Sicherheitsroutinen/Maschine für Instandhaltungs-, Reparatur-, Wartungs- und Einstellarbeiten vorbereiten @ 272\mod_1403522290336_78.docx @ 2051115 @ @ 1 WARNING! Risk of injury during repair, maintenance and adjustment work on the machine.

  • Page 24: Safety Stickers On The Machine

    Safety Pos: 17.13 /Überschriften/Überschriften 2/P-T/Sicherheitsaufkleber an der Maschine @ 190\mod_1381331374791_78.docx @ 1624956 @ 2 @ 1 Safety stickers on the machine Pos: 17.14 /Überschriften/Überschriften 3/K-O/Lage und Bedeutung der Sicherheitsaufkleber an der Maschine @ 190\mod_1381331498749_78.docx @ 1624985 @ 3 @ 1 4.6.1 Position and meaning of the safety stickers on the machine Pos: 17.15 /BA/Sicherheit/Schwader/Sicherheit Einführung Schwader_ohne Überschrift @ 302\mod_1413883110691_78.docx @ 2352366 @ @ 1...
  • Page 25 Safety Pos: 17.21 /BA/Sicherheit/4. Sicherheitsaufkleber/EU - ISO /939/939 100 4 (1x) Bestell-Nr. @ 198\mod_1384849800220_78.docx @ 1672274 @ @ 1 2) Order no. 939 100 4 (1x) Pos: 17.22 /BA/Sicherheit/4. Sicherheitsaufkleber/EU - ISO /939/939 100 4 Bild/Text @ 198\mod_1384849817642_78.docx @ 1672303 @ @ 1 Danger if the maximum permitted PTO speed or the maximum 939 100-4 540/...
  • Page 26 Safety Pos: 17.31 /BA/Sicherheit/Aufkleber/Schwader/Sicherheitsaufkleber Schwader TC 680_TC 760 Bild @ 279\mod_1405063677788_78.docx @ 2147075 @ @ 1 RH+LH RH+LH RH+LH RH+LH RH+LH RH+LH SW700081_2 Fig. 2 RH = right-hand side of the machine / LH = left-hand side of the machine Pos: 17.32 /Layout Module /----------------Leerzeile-------------------- @ 240\mod_1395147357027_0.docx @ 1890988 @ @ 1 Pos: 17.33 /BA/Sicherheit/4.

  • Page 27: Re-Ordering The Adhesive Safety And Information Labels

    The surface for affixing the adhesive label must be clean and free of dirt, oil and grease. Pos: 17.39 /Überschriften/Überschriften 3/A-E/A/Ansprechpartner @ 0\mod_1195569394286_78.docx @ 839 @ 3 @ 1 4.6.4 Contact Pos: 17.40 /BA/Adressen/Adresse Maschinenfabrik KRONE Spelle @ 0\mod_1195568531083_78.docx @ 734 @ @ 1 Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Strasse 10 D-48480 Spelle (Germany) Telephone: + 49 (0) 59 77/935-0 (Head Office) Fax.: + 49 (0) 59 77/935-339 (Head Office)

  • Page 28: Machine Description

    Machine Description Pos: 20.1 /Überschriften/Überschriften 1/K-O/Maschinenbeschreibung @ 107\mod_1334231806004_78.docx @ 965201 @ 1 @ 1 Machine Description Pos: 20.2 /Überschriften/Überschriften 2/K-O/Maschinenübersicht @ 0\mod_1195565731130_78.docx @ 555 @ 2 @ 1 Machine overview Pos: 20.3 /BA/Maschinenbeschreibung/Maschinenübersicht/Schwader/Maschinenübersicht Swadro TC 680_TC 760 @ 293\mod_1411396260228_78.docx @ 2305202 @ @ 1 19 18 15 14 SW700059_1...
  • Page 29 Machine Description 1) Hoop guard 8) Universal shaft bracket 15) Rotor chassis 2) Outrigger arm 9) Parking support 16) Rotor gearbox 3) Warning panel 10) Frame front 17) Universal shaft rotary drive 4) Frame rear 11) Support tine guards 18) Overload protection 5) Wheel chock 12) Electronic rotor height 19) Main gearbox...

  • Page 30: Identification Plate

    Authentic KRONE spare parts and accessories authorised by the manufacturer help to ensure safety. The use of spare parts, accessories and other devices which are not manufactured, tested or approved by KRONE will result in the revoking of the liability for damages resulting thereof.

  • Page 31: Overload Protection

    Machine Description Pos: 20.11 /Überschriften/Überschriften 2/U-Z/Überlastsicherung @ 2\mod_1202465560433_78.docx @ 59567 @ 2 @ 1 Overload protection Pos: 20.12 /BA/Bedienung /Schwader/Überlastsicherung/Hinweis Überlastsicherung nicht verändern @ 2\mod_1202465626026_78.docx @ 59586 @ @ 1 Note The overload protection must not be changed. The guarantee becomes invalid if an overload protection is used other the protection provided! Pos: 20.13 /BA/Bedienung /Schwader/Überlastsicherung/Überlastsicherung Bild Swadro 700#_800# @ 133\mod_1350034429144_78.docx @ 1180881 @ @ 1 SW700069...

  • Page 32: Technical Data Of The Machine

    3995 Height with tine arms folding 3580 Length 5900 Width 2900 Pos: 20.16.7 /BA/Einleitung/Technische Daten/Schwader/Schwader 700#_800#/Technische Daten: Abmessungen in Arbeitsstellung Swadro TC 680 @ 221\mod_1391610890909_78.docx @ 1792195 @ @ 1 Dimensions in Working Position Height 1600 Length 5900 Width 6800 Acreage output 6.5-7 ha/h...
  • Page 33 Warning panels Standard Universal shaft Wide angle Pos: 20.16.12 /BA/Einleitung/Technische Daten/Schwader/Schwader 700#_800#/Technische Daten: Ausrüstung der Maschine (optional) Swadro TC 680 @ 293\mod_1411471594152_78.docx @ 2306237 @ @ 1 Equipment of the machine (optional) Swath cloth Tine security system Hydraulic single-rotor lifting mechanism with spring relief...
  • Page 34 Technical Data of the Machine Pos: 20.16.16 /Abkürzungen /Abkürzungen sprachneutral/Schwader/Swadro TC 760 @ 204\mod_1386149432648_0.docx @ 1701725 @ @ 1 Swadro TC 760 Pos: 20.16.17 /BA/Einleitung/Technische Daten/Schwader/Straßenfahrt: geschwenkte Kreiselarme 4 Meter nicht überschreiten @ 292\mod_1411374357634_78.docx @ 2304398 @ @ 1 Road travel is only permitted with the swivelled outrigger arms in transport position. The maximum height of 4 m must not be exceeded.
  • Page 35 Technical Data of the Machine Pos: 20.16.23 /BA/Einleitung/Technische Daten/Schwader/Schwader 700#_800#/Technische Daten: Mindestanforderung an den Traktor SW 800# @ 132\mod_1349852096672_78.docx @ 1174909 @ @ 1 Minimum Requirements for the Tractor Power requirement 37/50 kW/HP P.T.O. speed max. 540 rpm Lighting voltage 12 volt, 7-pin plug Voltage control unit (optional) 12 volt, 3-pin plug...

  • Page 36: Tyres

    Technical Data of the Machine Pos: 20.16.27 /BA/Einleitung/Technische Daten/Schwader/Schwader 700#_800#/Technische Daten: Ausrüstung der Maschine (Beipack) Swadro TC 760 @ 294\mod_1411473024703_78.docx @ 2307598 @ @ 1 Equipment of the machine (accessories kit) Swath cloth Tine security system Hydraulic single-rotor lifting mechanism with spring relief Hydraulic working width adjustment Guide wheels staying in operating for a certain period of time before being switched off completely...

  • Page 37: Control And Display Elements

    Control and Display Elements Pos: 23.1 /Überschriften/Überschriften 1/A-E/Bedien- und Anzeigeelemente @ 107\mod_1334231983896_78.docx @ 965285 @ 1 @ 1 Control and Display Elements Pos: 23.2 /BA/Maschinenbeschreibung/SchwaderFunktionsübersicht Standard (2014-11-18 14:43:16) @ 250\mod_1396939092825_78.docx @ 1936072 @ @ 1 The following table shows the functions on the machine (depending on machine design) Function Description Crank on left rotor...
  • Page 38 Control and Display Elements Pos: 23.4 /BA/Maschinenbeschreibung/Schwader/Funktionsübersicht Hydraulische Bedieneinheit @ 225\mod_1392617499198_78.docx @ 1821315 @ @ 1 With Hydraulic Single-Rotor Lifting Mechanism Design SW700086_1 Fig. 8 The position of the switching valve (1) determines which rotor is lifted or lowered. The actual movement is made via the single-acting control unit.
  • Page 39 Control and Display Elements Pos: 23.6.1 /Überschriften/Zwischenüberschriften/Bei Ausführung elektrisch-hydraulische Einkreiselaushebung @ 302\mod_1413984247854_78.docx @ 2354790 @ @ 1 In case of electro-hydraulic single-rotor lifting mechanism design Pos: 23.6.2 /BA/Maschinenbeschreibung/Schwader/elektrisch-hydraulische Einkreiselaushebung Mittelschwader_Bild @ 302\mod_1413983953479_78.docx @ 2354697 @ @ 1 SW700087_1 Fig. 9 Pos: 23.6.3 /Layout Module /----------------Leerzeile 5 Pt.-------------------- @ 120\mod_1342592918145_0.docx @ 1092566 @ @ 1 Pos: 23.6.4 /BA/Maschinenbeschreibung/Schwader/elektrisch-hydraulische Einkreiselaushebung_Tabelle @ 302\mod_1413984135358_78.docx @ 2354759 @ @ 1 The following table explains the function of the individual...

  • Page 40: Commissioning

    Commissioning Pos: 25.1 /Überschriften/Überschriften 1/A-E/Erstinbetriebnahme @ 0\mod_1196314201498_78.docx @ 5855 @ 1 @ 1 Commissioning Pos: 25.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Erstinbetriebnahme/Warnung - Erstinbetriebnahme nur von autorisierter Fachperson @ 111\mod_1336724783740_78.docx @ 987284 @ @ 1 WARNING! Risk of accident or damage to the machine due to an incorrect initial operation! Only an authorized service technician is permitted to carry out the initial operation.

  • Page 41: Preparations On Tractor

    Commissioning Pos: 25.10.1 /Überschriften/Überschriften 2/U-Z/Vorbereitungen am Traktor @ 2\mod_1202363643678_78.docx @ 58694 @ 2 @ 1 Preparations on tractor Pos: 25.10.2 /Überschriften/Überschriften 3/U-Z/Unterlenker einstellen @ 6\mod_1214454896135_78.docx @ 94186 @ 3 @ 1 8.3.1 Adjusting the lower suspension arms Pos: 25.10.3 /BA/Erstinbetriebnahme/Schwader/Swadro 807_810_907/Bild_Aushubvorrichtung Traktor @ 2\mod_1202364384960_78.docx @ 58789 @ @ 1 KS-0-030 Fig.

  • Page 42: Pto Shaft

    Commissioning Pos: 25.17.1 /Überschriften/Überschriften 2/F-J/Gelenkwelle @ 0\mod_1199781879794_78.docx @ 34542 @ 2 @ 1 PTO shaft Pos: 25.17.2 /Überschriften/Überschriften 3/K-O/Längenanpassung @ 1\mod_1201687632810_78.docx @ 53589 @ 3 @ 1 8.5.1 Length adjustment Pos: 25.17.3 /BA/Erstinbetriebnahme/Gelenkwelle/Traktorwechsel Gelenkwellenlänge beachten @ 6\mod_1214996938591_78.docx @ 97742 @ @ 1 Caution! - Changing the tractor Effect: Damage to the machine When using the machine for the first time and whenever changing the tractor Check PTO shaft...

  • Page 43: Regulating Direction Of Travel

    Commissioning Pos: 25.19 /Überschriften/Überschriften 2/F-J/Fahrtrichtung regulieren @ 36\mod_1263299717731_78.docx @ 338702 @ 2 @ 1 Regulating direction of travel Pos: 25.20 /BA/Einstellungen/Schwader/Fahrtrichtung regulieren nur von Fachpersonal_Querlenker voreingestellt @ 133\mod_1350302246866_78.docx @ 1182270 @ @ 1 The track control arm has been preset in the works of the manufacturer. Check the straight-ahead driving with hitched machine.

  • Page 44: Start-Up

    Start-up Pos: 27.1 /Überschriften/Überschriften 1/F-J/Inbetriebnahme @ 0\mod_1196327075811_78.docx @ 6375 @ 1 @ 1 Start-up Pos: 27.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 45: Preparations On Tractor

    Start-up Pos: 27.6.1 /Überschriften/Überschriften 2/U-Z/Vorbereitungen am Traktor @ 2\mod_1202363643678_78.docx @ 58694 @ 2 @ 1 Preparations on tractor Pos: 27.6.2 /Überschriften/Überschriften 3/U-Z/Unterlenker einstellen @ 6\mod_1214454896135_78.docx @ 94186 @ 3 @ 1 9.1.1 Adjusting the lower suspension arms Pos: 27.6.3 /BA/Erstinbetriebnahme/Schwader/Swadro 807_810_907/Bild_Aushubvorrichtung Traktor @ 2\mod_1202364384960_78.docx @ 58789 @ @ 1 KS-0-030 Fig.

  • Page 46: Connect The Machine To The Tractor

    Start-up Pos: 27.9 /Überschriften/Überschriften 2/K-O/Maschine an den Traktor ankuppeln @ 279\mod_1405350506791_78.docx @ 2150095 @ 2 @ 1 Connect the machine to the tractor Pos: 27.10 /BA/Erstinbetriebnahme/Wender/Hinweis - Je nach Traktortyp evtl. Anhängekupplung abbauen. @ 172\mod_1370506026261_78.docx @ 1479993 @ @ 1 CAUTION! –...

  • Page 47: Connecting The Hydraulic Lines

    SW9070003_1 Fig. 16 Pos: 27.22 /Abkürzungen /Abkürzungen sprachneutral/Schwader/Swadro TC 680 / Swadro TC 760 @ 204\mod_1386149582296_0.docx @ 1701748 @ @ 1 Swadro TC 680 / Swadro TC 760 Pos: 27.23 /BA/Inbetriebnahme/Hydraulikkupplungen anschließen alle Maschinen/Hydraulikkupplungen anschließen rot 1+ @ 213\mod_1390207396349_78.docx @ 1749335 @ @ 1 •...

  • Page 48: Lighting Connection

    Start-up Pos: 27.31 /Überschriften/Überschriften 2/A-E/Beleuchtung anschließen @ 33\mod_1254385308979_78.docx @ 319105 @ 2 @ 1 Lighting connection Pos: 27.32 /BA/Inbetriebnahme/Schwader/Hinweis Sauberkeit der Stecker und Steckdosen @ 2\mod_1202399563131_78.docx @ 59273 @ @ 1 Note Before inserting the plugs, make certain the plugs and sockets are clean and dry. Dirt and moisture may result in short circuits! Pos: 27.33 /BA/Inbetriebnahme/Schwader/Anschluss Beleuchtung/Anschluss Beleuchtung Bild SW TC 680_TC 760_TC 760 X-tr @ 214\mod_1390396347380_78.docx @ 1755543 @ @ 1 SW700089_1...

  • Page 49: Connecting The Operation

    Start-up Pos: 27.36 /Überschriften/Überschriften 2/A-E/Bedienung anschließen @ 302\mod_1414049404753_78.docx @ 2355806 @ 2 @ 1 Connecting the Operation Pos: 27.37 /Abkürzungen /Bei Variante Plus @ 302\mod_1414047391014_78.docx @ 2355775 @ @ 1 In case of Plus version Pos: 27.38 /BA/Inbetriebnahme/Schwader/Hinweis Sauberkeit der Stecker und Steckdosen @ 2\mod_1202399563131_78.docx @ 59273 @ @ 1 Note Before inserting the plugs, make certain the plugs and sockets are clean and dry.

  • Page 50: Install The Pto Shaft

    Start-up Pos: 27.41 /Überschriften/Überschriften 2/F-J/Gelenkwelle montieren @ 2\mod_1202398342788_78.docx @ 59253 @ 2 @ 1 Install the PTO shaft Pos: 27.42 /BA/Erstinbetriebnahme/Gelenkwelle/Traktorwechsel Gelenkwellenlänge beachten @ 6\mod_1214996938591_78.docx @ 97742 @ @ 1 Caution! - Changing the tractor Effect: Damage to the machine When using the machine for the first time and whenever changing the tractor Check PTO shaft for the correct length.

  • Page 51: Using The Safety Chain

    Start-up Pos: 27.46.1 /Überschriften/Überschriften 2/P-T/Sicherungskette verwenden @ 6\mod_1214542336632_78.docx @ 94799 @ 2 @ 1 Using the safety chain Pos: 27.46.2 /BA/Inbetriebnahme/Sicherungskette USA/WARNUNG - Falsch dimensionierte Sicherungskette verwendet mit Variante @ 180\mod_1376576652355_78.docx @ 1547873 @ @ 1 WARNING! When using a wrongly dimensioned safety chain, the safety chain may tear if the machine loosens unintentionally.
  • Page 52 Start-up Pos: 27.46.10 /BA/Inbetriebnahme/Sicherungskette USA/Sicherungskette an der Maschine montieren_Bild_SW 800# / 907-1, TC 680_760 @ 304\mod_1414672909325_78.docx @ 2364064 @ @ 1 SW9000042_1 Fig. 21 Pos: 27.46.11 /BA/Inbetriebnahme/Sicherungskette USA/Sicherungskette an der Maschine montieren_Text @ 168\mod_1368510725089_78.docx @ 1456755 @ @ 1 • Install the safety chain (1) on the machine.

  • Page 53: Swivelling Parking Support Into Transport Position

    Start-up Pos: 27.48 /Überschriften/Überschriften 2/A-E/Abstellstütze in Transportstellung schwenken @ 10\mod_1221637347634_78.docx @ 135539 @ 2 @ 1 Swivelling parking support into transport position Pos: 27.49 /BA/Inbetriebnahme/Schwader/Abstellstütze hochschwenken Bild @ 134\mod_1350458858615_78.docx @ 1186403 @ @ 1 SW700084 Fig. 22 Pos: 27.50 /BA/Inbetriebnahme/Schwader/Abstellstütze hochschwenken @ 156\mod_1363933455290_78.docx @ 1379305 @ @ 1 •...

  • Page 54: Driving And Transport

    Driving and Transport Pos: 29.1 /Überschriften/Überschriften 1/F-J/Fahren und Transport @ 0\mod_1196330049217_78.docx @ 6553 @ 1 @ 1 Driving and Transport Pos: 29.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 55: Preparations For Road Travel

    Driving and Transport Pos: 29.7 /Überschriften/Überschriften 2/U-Z/Vorbereitungen zur Straßenfahrt @ 25\mod_1244092605963_78.docx @ 254666 @ 2 @ 1 10.1 Preparations for road travel Pos: 29.8 /BA/Fahren und Transport/Schwader/Prüfen Sie vor der Straßenfahrt, dass Swadro TC 680_TC 760 @ 302\mod_1414054680489_78.docx @ 2356095 @ @ 1 SW700063 SW700062_1 Fig.

  • Page 56: Travelling On An Incline

    Driving and Transport Pos: 29.10 /BA/Bedienung /SchwaderFahren im Hangbereich_Schwader (2014-11-17 14:02:18) @ 2\mod_1202724671955_78.docx @ 60415 @ 2 @ 1 10.2 Travelling on an incline Danger! - Travelling on an incline (danger of turning over!). Effect: Danger to life, injuries or damage to the machine. •...

  • Page 57: Switching Off The Machine

    Driving and Transport Pos: 29.15 /Überschriften/Überschriften 2/K-O/Maschine abstellen @ 196\mod_1384184875882_78.docx @ 1661525 @ 2 @ 1 10.3 Switching off the machine Pos: 29.16 /BA/Sicherheit/2. Vorangestellte Warnhinweise/Warnung - Maschine sicher abstellen ohne Traktor_Unterlegkeile @ 278\mod_1404972644211_78.docx @ 2083305 @ @ 1 WARNING! Risk of injury due to the unsecured machine rolling away! If the machine is not secured against rolling away when it has been switched off, there is a risk of people being injured by the machine rolling away in an uncontrolled manner.

  • Page 58: Operation

    Operation Pos: 31.1 /Überschriften/Überschriften 1/A-E/Bedienung @ 0\mod_1199789505403_78.docx @ 34825 @ 1 @ 1 Operation Pos: 31.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 59: Lowering Outrigger Arms Into Working Position

    Operation Pos: 31.9 /Überschriften/Überschriften 2/K-O/Auslegearme in Arbeitsstellung absenken @ 303\mod_1414129704864_78.docx @ 2356706 @ 2 @ 1 11.2 Lowering Outrigger Arms into Working Position Pos: 31.10 /BA/Sicherheit/8. Voraussetzungen/Handlungsanweisung für alle Maschinen/Handlungsanweisung: Maschine stillsetzen und sichern @ 274\mod_1404365253849_78.docx @ 2065151 @ @ 1 •...

  • Page 60: For Design With Hydraulic Single-Rotor Lifting Mechanism

    Operation Pos: 31.15 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung mit hydraulischer Einkreiselaushebung @ 77\mod_1310050459478_78.docx @ 667495 @ 3 @ 1 11.2.2 For design with hydraulic single-rotor lifting mechanism Pos: 31.16 /BA/Bedienung /Schwader/Kreiselarme senken/heben/Kreiselarme senken hydraulische Einkreiselaushebung SW TC 680_760 @ 214\mod_1390381679853_78.docx @ 1755064 @ @ 1 SW700066_1 Fig.

  • Page 61: In Case Of Electro-Hydraulic Single-Rotor Lifting Mechanism Design

    Operation Pos: 31.18 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung mit elektrisch-hydraulischer Einkreiselaushebung @ 302\mod_1414129218204_78.docx @ 2356675 @ 3 @ 1 11.2.3 In Case of Electro-Hydraulic Single-Rotor Lifting Mechanism Design Pos: 31.19 /BA/Bedienung /Schwader/Kreiselarme senken/heben/Kreiselarme senken -elektrisch SW TC 680_760 @ 303\mod_1414415758165_78.docx @ 2359157 @ @ 1 SW700067_1 Fig.

  • Page 62: Swivel Tine Arms To Working Position

    Operation Pos: 31.22 /Überschriften/Überschriften 2/U-Z/Zinkenarme in Arbeitstellung schwenken @ 2\mod_1202709358751_78.docx @ 59873 @ 2 @ 1 11.3 Swivel tine arms to working position. Pos: 31.23 /BA/Sicherheit/8. Voraussetzungen/Handlungsanweisung für alle Maschinen/Handlungsanweisung: Maschine stillsetzen und sichern @ 274\mod_1404365253849_78.docx @ 2065151 @ @ 1 •...

  • Page 63: For Design With Collapsible Tine Arm

    Operation Pos: 31.26 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung Zinkenarm klappbar @ 77\mod_1310050676669_78.docx @ 667550 @ 3 @ 1 11.3.1 For design with collapsible tine arm Pos: 31.27 /BA/Bedienung /Schwader/Zinken / Zinkenarme/Zinkenarme in die Arbeitsstellung schwenken @ 304\mod_1414578966773_78.docx @ 2362456 @ @ 1 SW9070017 Fig.

  • Page 64: Setting The Working Height

    Operation Pos: 31.33 /Überschriften/Überschriften 2/A-E/Arbeitshöhe einstellen @ 224\mod_1392279849895_78.docx @ 1815275 @ 2 @ 1 11.5 Setting the Working Height Pos: 31.34 /BA/Bedienung /Schwader/Kreiselhöhe einstellen (vorher: Arbeitstiefe)/Einstellen der Arbeitshöhe - mechanisch SW TC 680_760 @ 303\mod_1414136111440_78.docx @ 2357067 @ @ 1 Setting the working height in case of the mechanical version SW700070_1 Fig.
  • Page 65 Operation Pos: 31.36 /BA/Bedienung /Schwader/Kreiselhöhe einstellen (vorher: Arbeitstiefe)/Einstellen der Arbeitshöhe elektrisch SW TC 680_760 @ 303\mod_1414136392843_78.docx @ 2357098 @ @ 1 Setting the working height in case of electrical design (optional)) SW700088_1 Fig. 34 The working height can be adapted to crop and terrain while the machine is in operation or in headland position.

  • Page 66: Adjusting The Working Width

    Operation Pos: 31.38 /Überschriften/Überschriften 2/A-E/Arbeitsbreite einstellen @ 77\mod_1310103035622_78.docx @ 667585 @ 2 @ 1 11.6 Adjusting the Working Width Pos: 31.39 /BA/Sicherheit/8. Voraussetzungen/Handlungsanweisung für alle Maschinen/Handlungsanweisung: Maschine stillsetzen und sichern @ 274\mod_1404365253849_78.docx @ 2065151 @ @ 1 • Shut down and safeguard the machine, see chapter Safety -> Safety routines, "Shutting down and safeguarding the machine".
  • Page 67 Operation Pos: 31.45 /BA/Bedienung /Schwader/Bei Ausführung hydraulische Arbeitsbreitenverstellung: @ 77\mod_1310550540011_78.docx @ 669183 @ @ 1 For design with hydraulic working width setting: Pos: 31.46 /BA/Bedienung /Schwader/Achtung Einstellen der Arbeitsbreite SW 700_800_900 @ 77\mod_1310103302890_78.docx @ 667613 @ @ 1 Caution! - Adjusting the working width Effect: Damage to the machine •...

  • Page 68: Move The Hoop Guards To Transport Position

    Operation Pos: 31.51 /Überschriften/Überschriften 2/P-T/Schutzbügel in Transportstellung bringen @ 2\mod_1202975248858_78.docx @ 63516 @ 2 @ 1 11.7 Move the hoop guards to transport position. Pos: 31.52 /BA/Sicherheit/7. Gefahrenhinweise alt/Wartung - Quetschgefahr @ 2\mod_1202971999343_78.docx @ 63374 @ @ 1 Warning - Crush hazard! Effect: Injury to hands Do not hold onto hoop guards to swivel within range of the rotating points.

  • Page 69: Swivelling Tine Arms Into Transport Position

    Operation Pos: 31.56 /Überschriften/Überschriften 2/U-Z/Zinkenarme in Transportstellung @ 2\mod_1202719789158_78.docx @ 60199 @ 2 @ 1 11.8 Swivelling tine arms into transport position Pos: 31.57 /BA/Sicherheit/8. Voraussetzungen/Handlungsanweisung für alle Maschinen/Handlungsanweisung: Maschine stillsetzen und sichern @ 274\mod_1404365253849_78.docx @ 2065151 @ @ 1 •...

  • Page 70: For Design With Collapsible Tine Arm

    Operation Pos: 31.62 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung Zinkenarm klappbar @ 77\mod_1310050676669_78.docx @ 667550 @ 3 @ 1 11.8.3 For design with collapsible tine arm Pos: 31.63 /BA/Bedienung /Schwader/Zinken / Zinkenarme/Zinkenarme in Transportstellung schwenken @ 2\mod_1202719970173_78.docx @ 60219 @ @ 1 SW9070018 Figure 38 Firstly: •...

  • Page 71: Raising Outrigger Arms Into Transport Position

    Operation Pos: 31.65 /Überschriften/Überschriften 2/K-O/Auslegearme in Transportstellung anheben @ 303\mod_1414129961702_78.docx @ 2356737 @ 2 @ 1 11.9 Raising Outrigger Arms into Transport Position Pos: 31.66 /BA/Sicherheit/7. Gefahrenhinweise alt/Schwader/Achtung - Ausheben der Kreisel Zapfwelle abschalten @ 2\mod_1202717797986_78.docx @ 60142 @ @ 1 Caution! Before swivelling the mowing unit up into transport position, turn off the PTO.

  • Page 72: For Design With Hydraulic Single-Rotor Lifting Mechanism

    Operation Pos: 31.73 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung mit hydraulischer Einkreiselaushebung @ 77\mod_1310050459478_78.docx @ 667495 @ 3 @ 1 11.9.2 For design with hydraulic single-rotor lifting mechanism Pos: 31.74 /BA/Bedienung /Schwader/Kreiselarme senken/heben/Kreiselarme heben mit Einkreiselaushebung Bild Swadro TC 680_TC 760_TC 760 X-tr @ 221\mod_1391691219749_78.docx @ 1799015 @ @ 1 SW700073_1 Fig.

  • Page 73: In Case Of Electro-Hydraulic Single-Rotor Lifting Mechanism Design

    Operation Pos: 31.78 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung mit elektrisch-hydraulischer Einkreiselaushebung @ 302\mod_1414129218204_78.docx @ 2356675 @ 3 @ 1 11.9.3 In Case of Electro-Hydraulic Single-Rotor Lifting Mechanism Design Pos: 31.79 /BA/Bedienung /Schwader/Kreiselarme senken/heben/Kreiselarme heben elektrisch Bild SW TC 680_760 @ 206\mod_1386598897039_78.docx @ 1711860 @ @ 1 SW700074_1 Fig.

  • Page 74: Protecting The Tine Tips (Transport Position And Rotary Rake Switched Off)

    Operation Pos: 31.83 /Überschriften/Überschriften 2/U-Z/Zinkenschutze anbringen @ 36\mod_1263218287043_78.docx @ 338452 @ 2 @ 1 11.10 Protecting the tine tips (transport position and rotary rake switched off) Pos: 31.84 /BA/Bedienung /Schwader/Zinken / Zinkenarme/Zinkenschutze anbringen Bild SW TC 680_760 @ 213\mod_1389944201475_78.docx @ 1747510 @ @ 1 SW700075_1 Fig.

  • Page 75: Selecing Rotor Operation

    Operation Pos: 31.87 /BA/Bedienung /Schwader/Schwaden/Kreiselbetrieb wählen @ 134\mod_1350632999853_78.docx @ 1190195 @ 2 @ 1 11.11 Selecing Rotor Operation Depending on how the machine is equipped, different rotor operations can be selected with the rotary rake. Twin-rotor operation: Swath placement to the middle with right and left rotor Single rotor operation: Swath placement to the middle with left rotor Single rotor operation: Swath placement to the middle with the right rotor Pos: 31.88 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung mit hydraulischer Einkreiselaushebung @ 77\mod_1310050459478_78.docx @ 667495 @ 3 @ 1...

  • Page 76: In Case Of Electro-Hydraulic Single-Rotor Lifting Mechanism Design

    Operation Pos: 31.91 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung mit elektrisch-hydraulischer Einkreiselaushebung @ 302\mod_1414129218204_78.docx @ 2356675 @ 3 @ 1 11.11.2 In Case of Electro-Hydraulic Single-Rotor Lifting Mechanism Design Pos: 31.92 /BA/Bedienung /Schwader/Schwaden/Kreiselbetriebe bei Ausführung elektrische Einkreiselaushebung @ 303\mod_1414136697549_78.docx @ 2357189 @ @ 1 SW700087_1 Fig.

  • Page 77: Travelling Speed Und Drive Speed

    Operation Pos: 31.94 /BA/Bedienung /Schwader/Fahrgeschwindigkeit und Antriebsdrehzahl @ 2\mod_1202743688330_78.docx @ 60967 @ 2 @ 1 11.12 Travelling speed und drive speed The travelling speed and drive speed while swathing depend on: • forage quantity • ground • degree of dryness Use these as rough guidelines: •...
  • Page 78 Operation Pos: 33 /Layout Module /Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ @ 1 This page has been left blank deliberately!! Pos: 34 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 79: Settings

    Settings Pos: 35.1 /Überschriften/Überschriften 1/A-E/Einstellungen @ 0\mod_1199868783862_78.docx @ 36141 @ 1 @ 1 Settings Pos: 35.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 80: Setting The Rotor Inclination

    Settings Pos: 35.6.1 /Überschriften/Überschriften 2/K-O/Kreiselneigung einstellen @ 191\mod_1381819931154_78.docx @ 1631074 @ 2 @ 1 12.1 Setting the Rotor Inclination Pos: 35.6.2 /BA/Einstellungen/Schwader/Kreiselfahrwerk/Kreiselneigung einstellen Text Einleitung Swadro TC 680_TC 760 @ 223\mod_1392114706229_78.docx @ 1808993 @ @ 1 The rotor pitch angle has been set at a transverse angle to the chassis in the factory. If the crops are not picked up properly, the working quality can be improved by adjusting the rotor pitch.

  • Page 81: For The Version With Trailing Guide Wheels (Optional)

    Settings Pos: 35.6.14 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung nachlaufende Tasträder (optional) @ 305\mod_1415611377646_78.docx @ 2370272 @ 3 @ 1 12.1.2 For the Version with Trailing Guide Wheels (optional) Pos: 35.6.15 /BA/Einstellungen/Schwader/Kreiselfahrwerk/Kreiselfahrwerk Bild nachlaufendes Rad Swadro TC 680_TC 760_TS 620_TS 680 @ 247\mod_1396423997182_78.docx @ 1925374 @ @ 1 SW700091_1 Fig.

  • Page 82: With Tandem Chassis Version (Optional)

    Settings Pos: 35.6.23 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung Tandemfahrwerk (optional) @ 223\mod_1392126673159_78.docx @ 1810363 @ 3 @ 1 12.1.3 With tandem chassis version (optional) Pos: 35.6.24 /BA/Einstellungen/Schwader/Kreiselfahrwerk/Kreiselfahrwerk Bild Tandem Swadro TC 680_TC 760_TS 620_TS 680 @ 247\mod_1396423777783_78.docx @ 1925345 @ @ 1 SW700093 Fig.

  • Page 83: Fixing The Trailing Guide Wheels

    Settings Pos: 35.8 /Überschriften/Überschriften 2/K-O/Nachlaufende Tasträder festsetzen @ 305\mod_1415611609451_78.docx @ 2370303 @ 2 @ 1 12.2 Fixing the Trailing Guide Wheels Pos: 35.9 /BA/Einstellungen/Schwader/Kreiselfahrwerk/Festsetzen der nachlaufenden Tasträder_Bild @ 305\mod_1415610205927_78.docx @ 2370211 @ @ 1 SW700095 Fig. 48 Pos: 35.10 /BA/Einstellungen/Schwader/Kreiselfahrwerk/Festsetzen der nachlaufenden Tasträder_Text @ 305\mod_1415605983523_78.docx @ 2370181 @ @ 1 In order to prevent the machine from drifting off when driving on the slope, fix the trailing guide wheels.

  • Page 84: Maintenance

    Effect: Danger to life, serious injuries or loss of warranty claims as well as exclusion of liability • Use only authentic KRONE spare parts and accessories authorised by the manufacturer. The use of spare parts, accessories or additional equipment not manufactured, tested or approved by KRONE will exclude any liability for consequential damage.

  • Page 85: Maintenance Table

    Maintenance Pos: 37.8 /Überschriften/Überschriften 2/U-Z/Wartungstabelle @ 65\mod_1300369413064_78.docx @ 583966 @ 2 @ 1 13.2 Maintenance table Pos: 37.9 /BA/Wartung/Schwader/Wartungstabelle - Swadro TC 880_TC 880 X-tr @ 238\mod_1395046773618_78.docx @ 1884362 @ @ 1 Maintenance interval Maintenance work Rotor gearbox Maintenance-free (permanently lubricated with grease) Main gearbox Oil level check Oil change...

  • Page 86: Tightening Torques

    Maintenance Pos: 37.11 /Überschriften/Überschriften 2/A-E/Anzugsdrehmomente @ 45\mod_1277103093968_78.docx @ 410970 @ 2 @ 1 13.3 Tightening Torques Pos: 37.12 /BA/Wartung/Drehmomente / AnziehdrehmomenteDrehmomente (2014-11-13 08:18:01) @ 45\mod_1277102920578_78.docx @ 410945 @ @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the (unless otherwise indicated).

  • Page 87: Tightening Torques (Countersunk Screws)

    Maintenance Pos: 37.14 /Überschriften/Überschriften 2/A-E/Anzugsdrehmomente über Innensechskant @ 45\mod_1277106415765_78.docx @ 411230 @ 2 @ 1 13.4 Tightening Torques (Countersunk Screws) Pos: 37.15 /BA/Wartung/Drehmomente / AnziehdrehmomenteDrehmomente über Innensechskant (2014-11-14 13:04:06) @ 45\mod_1277106232328_78.docx @ 411205 @ @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the...

  • Page 88: Deviating Torque

    Maintenance Pos: 37.17 /Überschriften/Überschriften 2/A-E/Abweichendes Drehmoment @ 155\mod_1363620849669_78.docx @ 1373212 @ 2 @ 1 13.5 Deviating Torque Pos: 37.18 /BA/Wartung/Schwader/Zinken / Zinkenarme/Prüfen der Schrauben an den Zinken nach Wartungstabelle_Swadro TC 680_TC 760_TC 760 X-tr @ 222\mod_1392012676954_78.docx @ 1804815 @ 3 @ 1 13.5.1 Testing the Screws on the Tines SW700030_1...

  • Page 89: Tyres

    If tyres are not correctly fitted, it could explode when pumped up. This can cause serious injury. If you do not have sufficient experience of fitting tyres, have tyres fitted by the KRONE dealer or a qualified tyre specialist. •...

  • Page 90: Replacing The Tine Arms (In Case Of Repair)

    Maintenance Pos: 37.29.1 /Überschriften/Überschriften 2/A-E/Austausch der Zinkenarme (im Reparaturfall) @ 36\mod_1262854646297_78.docx @ 338320 @ 2 @ 1 13.7 Replacing the tine arms (in case of repair) Pos: 37.29.2 /BA/Wartung/Schwader/Zinken / Zinkenarme/Austausch der Zinkenarme (im Reparaturfall) Bild außer Swadro TS 800_TC 1000 @ 224\mod_1392272631028_78.docx @ 1814375 @ @ 1 SW700041_1 Fig.
  • Page 91 Maintenance Pos: 37.29.4 /BA/Wartung/Schwader/Zinken / Zinkenarme/Kleben der Zinkenarme @ 3\mod_1204276891493_78.docx @ 70234 @ @ 1 In case of repairs, the tine arms can be removed and replaced individually. • Unscrew the screws (1) of the tine arm • Loosen the bolts (2) on the nearby tine arms •...

  • Page 92: Replacing The Tines (In Case Of Repairs)

    Maintenance Pos: 37.31.1 /Überschriften/Überschriften 2/U-Z/Zinken tauschen (im Reparaturfall) @ 224\mod_1392293057621_78.docx @ 1816928 @ 2 @ 1 13.8 Replacing the tines (in case of repairs) Pos: 37.31.2 /BA/Wartung/Schwader/Zinken / Zinkenarme/Zinken tauschen (im Reparaturfall) mit Abweisblech Bild mit Tabelle @ 224\mod_1392293941470_78.docx @ 1817087 @ @ 1 SW9070092_1 Fig.

  • Page 93: Maintenance - Lubrication Chart

    Maintenance – lubrication chart Pos: 37.33.1 /Überschriften/Überschriften 1/U-Z/Wartung - Schmierplan @ 0\mod_1197359304198_78.docx @ 18232 @ 1 @ 1 Maintenance – lubrication chart Pos: 37.33.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 94: Lubrication Points On The Machine

    Maintenance – lubrication chart Pos: 37.33.8 /Überschriften/Überschriften 2/P-T/Schmierstellen an der Maschine @ 134\mod_1350390497999_78.docx @ 1183902 @ 2 @ 1 14.2 Lubrication Points on the Machine Pos: 37.33.9 /BA/Wartung/Hinweis aus Gründen der Übersicht @ 2\mod_1202799283498_78.docx @ 61453 @ @ 1 Note To make the illustration easier to read, the greasing points have only been shown on one side of the machine.
  • Page 95 Maintenance – lubrication chart Lubricate the lubrication points every 20 operating hours. Lubricate the lubrication points every 250 operating hours. Pos: 37.34 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 96: Maintenance - Hydraulic System

    Risk of injury as a result of incorrect handling of liquids under high pressure. Effect: Escaping high-pressure liquids can penetrate the skin and cause serious injury. Repair work on the hydraulic system may only be performed by authorised KRONE professional workshops.

  • Page 97: Maintenance - Gearbox

    Maintenance - Gearbox Pos: 37.39 /Überschriften/Überschriften 1/U-Z/Wartung - Getriebe @ 2\mod_1203058202823_78.docx @ 64495 @ 1 @ 1 Maintenance - Gearbox Pos: 37.40 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 98: Main Gearbox

    Maintenance - Gearbox Pos: 37.51 /Überschriften/Überschriften 2/F-J/Hauptgetriebe @ 0\mod_1197005740033_78.docx @ 15416 @ 2 @ 1 16.1 Main gearbox Pos: 37.52 /BA/Wartung/Ölkontrolle_Wechsel/Schwader/Hauptgetriebe/Hauptgetriebe Bild SW 700#_800# @ 134\mod_1350484320827_78.docx @ 1188202 @ @ 1 SW700085 Fig. 56 Pos: 37.53 /BA/Wartung/Ölkontrolle_Wechsel/Ölkontrolle / Ölwechsel Intervall: siehe Kapitel Wartung „Wartungstabelle“ @ 134\mod_1350483605921_78.docx @ 1188115 @ @ 1 Interval for oil level check and oil change: refer to chapter Maintenance “Maintenance Table”...

  • Page 99: Special Equipment

    Special equipment Pos: 39.1 /Überschriften/Überschriften 1/P-T/Sonderausstattung @ 2\mod_1202808469779_78.docx @ 61649 @ 1 @ 1 Special equipment Pos: 39.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 100: Chain For Height Restriction Of Suspension Arms

    Special equipment Pos: 39.6 /BA/Sonderausstatung/Schwader/Kette zur Tiefenbegrenzung der Unterlenker @ 2\mod_1202808127295_78.docx @ 61611 @ 2 @ 1 17.2 Chain for height restriction of suspension arms Figure 58 • Secure chains (1) with a spring-type slotted straight pin (3) and a washer (2) at the suspension arm seats.

  • Page 101: Placing In Storage

    Placing in Storage Pos: 41.1 /Überschriften/Überschriften 1/A-E/Einlagerung @ 0\mod_1197385459120_78.docx @ 19966 @ 1 @ 1 Placing in Storage Pos: 41.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 102: At The End Of The Harvest Season

    Perform the necessary repair tasks during the time immediately after the harvest season. Draw up a list of all replacement parts you will need. This will make it easier for your KRONE dealer to process your orders and you will be certain that your machine will be ready for use at the beginning of the next season.

  • Page 103: Before The Start Of The New Season

    Placing in Storage Pos: 41.10 /Überschriften/Überschriften 2/U-Z/Vor Beginn der neuen Saison @ 0\mod_1197386024448_78.docx @ 20081 @ 2 @ 1 18.3 Before the Start of the New Season Pos: 41.11 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 2 @ 1 18.4 Special Safety Instructions Pos: 41.12 /BA/Sicherheit/7.

  • Page 104: Malfunctions - Causes And Remedies

    Malfunctions - Causes and Remedies Pos: 43.1 /Überschriften/Überschriften 1/P-T/Störungen - Ursachen und Behebung @ 0\mod_1200296925180_78.docx @ 39459 @ 1 @ 1 Malfunctions - Causes and Remedies Pos: 43.2 /BA/Sicherheit/2. Vorangestellte Warnhinweise/WARNUNG - Nichtbeachtung der grundlegenden Sicherheitshinweise alte Form @ 254\mod_1397485793575_78.docx @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.
  • Page 105 Malfunctions - Causes and Remedies Pos: 43.5 /BA/Störungen - Ursachen und Behebung/Schwader/Tabellarische Auflistung Schwader TC 680_TC 760 @ 304\mod_1414498565398_78.docx @ 2361055 @ @ 1 Malfunction Possible cause Remedy Rotor does not work smoothly. Working height is set too high. Lower working height. Working speed is too high.

  • Page 106: Disposal Of The Machine

    Disposal of the machine Pos: 45 /Überschriften/Überschriften 1/A-E/Entsorgung der Maschine @ 274\mod_1404207309028_78.docx @ 2060455 @ 1 @ 1 Disposal of the machine Pos: 46 /BA/Entsorgung der Maschine/Die Maschine entsorgen @ 274\mod_1404207434449_78.docx @ 2060544 @ 2 @ 1 20.1 Disposal of the machine After the service life of the machine has expired, the individual components of the machine must be disposed of properly.

  • Page 107: Appendix

    Appendix Pos: 48 /Überschriften/Überschriften 1/A-E/Anhang @ 1\mod_1202278612285_78.docx @ 58360 @ 1 @ 1 Appendix Pos: 49 /BA/Anhang/Schwader/Im Anhang finden Sie den Schaltplan @ 2\mod_1202811415263_78.docx @ 61821 @ @ 1 The circuit diagram can be found in the Appendix. === Ende der Liste für Textmarke Inhalt ===...
  • Page 113 Index Information Required for Questions and Orders 30 A  Install the PTO shaft .......... 50 Additional equipment and spare parts ....11 Intended use ............9 Adjusting the lower suspension arms ... 41, 45 K  Adjusting the Working Width ......66 Affixing the Adhesive Safety and Information Keeping safety devices functional .....
  • Page 114 Re-Ordering the Adhesive Safety and Information Structural changes to the machine ....10 Labels ............. 27 Supporting lifted machine and machine parts Replacing the tine arms(in case of repair) ..90 securely ............21 Replacing the tines (in case of repairs) ....92 Switching off the machine ........
  • Page 116 Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Straße 10, D-48480 Spelle Postfach 11 63, D-48478 Spelle Phone +49 (0) 59 77/935-0 +49 (0) 59 77/935-339 Internet: http://www.krone.de eMail: info.ldm@krone.de...

This manual is also suitable for:

Swadro tc 760

Table of Contents
