Handling the swather when in use
4.5 Removal from tractor
•
Make sure when setting down the swather disk, that the ground is even and firm!
•
Secure swather against rolling away before uncoupling!
•
Also observe all further safety instructions!
•
Choose a level, dry and appropriate load-bearing
surface.
•
Fold support downwards and lock in this position with
the strut (1).
•
Secure strut (1) with hairpin clip.
•
Uncouple universal drive shaft and store on the
mount (2) provided.
•
Disconnect the hydraulic hoses (1) and plug them
into the mounts provided.
•
Undo the connection of the lighting cables (2)
between tractor and swather and plug them into the
mounts provided.
•
Undo the power supply plug (3) (optional) between
tractor and swather and plug it into the mounts
provided.
IV - 10
1
2
1
SW700014
2
KS-0-087
3
SW101023
