Figure 4-46
360/ARC Hot Key
Page 4-24
091-00027-001 Rev A EBD Pilots Guide V&H .indb 24
Select Compass Type
Press the 360/ARC Hot Key (Figure 4-46) to alternately select either the 360°
1.
or ARC Compass Mode.
The Navigation Display changes and the Hot Key label reflects the currently selected
Compass Mode (Figures 4-47 and 4-48).
Figure 4-47
ARC CDI Compass Mode
Evolution Backup Display Pilot's Guide
Figure 4-48
360˚ Compass Mode
