2.1. Controls & Display Orientation
CONTROLS
Power Button
1
2 Range Buttons
3 Menu Button
Hot Key - Unused
4
Hot Key - Unused
5
6 360/ARC View
7 Hot Key - Unused
BARO
8
Top Knob
9
Top Button
10
11 Middle Button
12 Bottom Button
13 Bottom Knob
Automatic Dimming Photocell
14
microSD Card Slot
15
NOTE
Any numbered function omitted from this table is
intentional: the function is not included in the Basic
EBD configuration.
Page 2-2
091-00027-001 Rev A EBD Pilots Guide V&H .indb 2
ATTITUDE DISPLAY
Attitude Display
16
17 Aircraft Reference Symbol
19 Roll Pointer
Slip/Skid Indicator
20
Altitude Tape
21
22 Selected Altitude Field (controls the Altitude Bug)
23 Altitude Alerter
24 Numerical Altitude Indication, Altitude Drum/Pointer
Altitude Trend Vector
25
Altitude Bug
26
32 Airspeed Tape
33 Selected Airspeed Field
Airspeed Bug
34
Numerical Airspeed Indicator, Airspeed Drum/Pointer
35
DATA BAR
True Airspeed (TAS) or Mach number
38
Barometric Pressure Setting Field
39
40 Wind Direction and Speed
41 Wind Direction Arrow
Outside Air Temperature (OAT)
42
Ground Speed
43
Evolution Backup Display Pilot's Guide
NAVIGATION DISPLAY
Navigation Display
44
Ownship Symbol
45
Rate of Turn Indicator
48
49 Ground Track Marker
50 Numerical Direction Indicator
Selected Heading Field
52
Heading Bug
53
57 Vertical Speed Tape
66 Bottom Knob State
67 Top Knob State
Hot Key Label
68
Basemap Range
69
70 Declutter Level
Table 2-1 EBD Components
