Conventions

The following conventions, functionality, terminology, color philosophy,
and definitions are used in this manual and on the Evolution Backup
Display.

Terminology

The term "EBD", is used throughout this Pilot's Guide and refers to the Evolution Backup
Display. This publication is specifically for the Evolution Backup Display, Basic Landscape
and Portrait version.
Figure 1 shows a typical Evolution Backup Display. This guide uses the terminology
listed in Table 1 when referring to specific parts of the EBD and Chapter 4 provides an
in-depth discussion and step-by-step instructions for all the available functionality.
Example Graphics
There are two configurations of Evolution back up display. A portrait or vertical
layout and a landscape or horizontal layout. Many of the figures included in this Pilot's
Guide are screen shots of the Evolution Back up Display Basic Landscape version. The
functionality of the units is the same the only difference is the portrait and landscape
layout.
The example graphics and screen shots used throughout this Pilot's Guide are provided
for reference only and are taken from a simulated flight. They should not be used for
actual flights.
